godot-mcp-pilot
Model Context Protocol server for Godot 4 — Give AI assistants (Claude, Cursor, Cline, etc.) direct control over your Godot projects.
godot-mcp-pilot exposes Godot engine operations as MCP tools, letting AI assistants launch the editor, run projects, create and edit scenes, write GDScript, and inspect assets — all through natural language. Works for both 2D and 3D games.

"Create a CharacterBody3D player scene with a Camera3D and collision"
"Run the project and show me any errors"
"Add a DirectionalLight3D to the scene"
"Create a 2D platformer with sprites and tilemaps"Quick Start
1. Install
npm install -g godot-mcp-pilotOr use without installing:
npx godot-mcp-pilot2. Run the setup wizard
npx godot-mcp-pilot setup
# or, if installed globally:
godot-mcp-pilot-setupThe wizard will:
Auto-detect your Godot binary (checks Applications, Downloads, PATH)
Ask which AI client you use
Write the config to the right place for that client
Manual Setup
Claude Code (CLI / IDE extension)
Critical: Claude Code reads
.mcp.jsonfrom the directory where you launch it.
The file must be in your game project folder, not the godot-mcp-pilot folder.
# From inside your game project directory:
claude mcp add godot -- npx godot-mcp-pilotThis writes .mcp.json to your current directory. Then always launch Claude Code from that directory:
cd ~/games/my-platformer
claudeIf Godot isn't auto-detected (e.g. you never moved it out of ~/Downloads):
claude mcp add godot -e GODOT_PATH=/path/to/Godot.app/Contents/MacOS/Godot -- npx godot-mcp-pilotOr write .mcp.json manually in your game project root:
{
"mcpServers": {
"godot": {
"command": "npx",
"args": ["godot-mcp-pilot"],
"env": {
"GODOT_PATH": "/path/to/your/Godot"
}
}
}
}Claude Desktop
Claude Desktop uses a different config file — it does not read .mcp.json.
Edit ~/Library/Application Support/Claude/claude_desktop_config.json (macOS)
or %APPDATA%\Claude\claude_desktop_config.json (Windows):
{
"mcpServers": {
"godot": {
"command": "npx",
"args": ["godot-mcp-pilot"],
"env": {
"GODOT_PATH": "/path/to/your/Godot"
}
}
}
}Then quit and reopen Claude Desktop.
Cursor (.cursor/mcp.json)
{
"mcpServers": {
"godot": {
"command": "npx",
"args": ["godot-mcp-pilot"],
"env": {
"GODOT_PATH": "/path/to/your/Godot"
}
}
}
}Godot Path Detection
The server searches these locations automatically (in order):
OS | Paths checked |
macOS |
|
Linux |
|
Windows |
|
If auto-detection fails, set GODOT_PATH to the absolute path of your Godot executable.
2D and 3D Games
godot-mcp-pilot works equally well for 2D and 3D. Use the appropriate node types:
2D | 3D | |
Player |
|
|
Root |
|
|
Camera |
|
|
Mesh |
|
|
Collision |
|
|
Physics |
|
|
Light | — |
|
Example prompts:
"Create a 3D scene with a Node3D root, MeshInstance3D floor, and DirectionalLight3D"
"Add a CharacterBody3D with a CollisionShape3D using a CapsuleShape3D"
"Write a GDScript for 3D first-person movement"Features
Category | Tools |
System |
|
Editor / Run |
|
Scenes |
|
Nodes |
|
Scripts |
|
Project |
|
Assets |
|
UIDs |
|
Configuration
Environment Variable | Default | Description |
| auto-detected | Absolute path to the Godot executable |
|
| If |
|
| Print debug info to stderr |
Troubleshooting
"MCP server not connected" / tools not appearing
Claude Code: The .mcp.json must be in the directory where you run claude. Open a new terminal, cd into your game project, and run claude from there.
Claude Desktop: Make sure you edited the right file (claude_desktop_config.json, not .mcp.json) and fully quit and reopened the app.
Godot not found
Set GODOT_PATH explicitly in the config env block. On macOS, if you downloaded Godot but never moved it:
GODOT_PATH=/Users/yourname/Downloads/Godot.app/Contents/MacOS/GodotTo find where Godot is:
# macOS / Linux
find ~/Downloads ~/Applications /Applications -name "Godot" -type f 2>/dev/nullScene parse errors / malformed .tscn
If Godot refuses to load a scene edited by the MCP, check that instance= lines are unquoted:
# Correct
instance=ExtResource("1_abc")
# Wrong (Godot rejects this)
instance="ExtResource(\"1_abc\")"Run the project headless to see the exact error:
/path/to/Godot --path /path/to/project --headless --quit 2>&1MCP disconnects during a session
This is a known issue with some MCP host implementations. Workaround: close and reopen your AI client. The MCP server itself is stateless — reconnecting is safe.
Example Workflows
2D top-down shooter
"Create a 2D scene called Main.tscn"
"Add a CharacterBody2D called Player at the center"
"Create a movement + shooting script for the Player"
"Add an Area2D called Enemy that moves toward the player"
"Run the project and show errors"3D platformer
"Create a 3D scene with a StaticBody3D floor (MeshInstance3D box, scale 20x1x20)"
"Add a CharacterBody3D player with a CapsuleShape3D collision"
"Create a 3D character controller script with jump and gravity"
"Add a Camera3D as a child of the player with offset Vector3(0, 2, 5)"Read-Only Mode
READ_ONLY_MODE=true npx godot-mcp-pilotDisables all write tools. Useful for CI/CD or review workflows.
Development
git clone https://github.com/pushks18/godot-mcp-pilot
cd godot-mcp-pilot
npm install
npm run build
# Run the setup wizard
npm run setup
# Development mode (ts-node, no build step)
npm run devProject Structure
godot-mcp-pilot/
├── src/
│ ├── index.ts # Entry point
│ ├── server.ts # MCP server + tool routing
│ ├── config.ts # Godot path detection, env config
│ ├── godot-process.ts # Process management (spawn, capture)
│ ├── tools/
│ │ ├── system.ts # Version, project listing/info
│ │ ├── execution.ts # Launch editor, run/stop project
│ │ ├── scene.ts # Scene CRUD + node manipulation
│ │ ├── script.ts # GDScript read/write/analyze
│ │ ├── assets.ts # Asset listing/inspection
│ │ ├── project_settings.ts # Settings, autoloads, input maps
│ │ └── uid.ts # Godot 4 UID management
│ └── utils/
│ ├── path.ts # Path validation (prevents traversal)
│ ├── tscn.ts # .tscn parser and serializer
│ └── project_godot.ts # project.godot reader
└── scripts/
├── setup.js # Interactive setup wizard
└── godot_operations.gd # Bundled GDScript for runtime opsCompatibility
Godot 4.x (primary target — tested on 4.2, 4.3, 4.4)
Godot 3.x — basic tools work; scene format differences apply
MCP Protocol — 2024-11-05 spec
Node.js — 18+
Security
All file paths are validated to stay within the project directory (no path traversal)
launch_editorandrun_projectonly start processes with safe, predefined argsUse
READ_ONLY_MODE=truein untrusted environmentsThe server never executes arbitrary shell commands — only the Godot binary
License
MIT
