Roam Research MCP + CLI

Introduction

I created this project to solve a personal problem: I wanted to manage my Roam Research graph directly from Claude Code (and other LLMs). As I built the Model Context Protocol (MCP) server to give AI agents access to my notes, I realized the underlying tools were powerful enough to stand on their own.

What started as an backend for AI agents evolved into a full-featured Standalone CLI. Now, you can use the same powerful API capabilities directly from your terminal—piping content into Roam, searching your graph, and managing tasks—without needing an LLM at all.

Whether you want to give Claude superpowers over your knowledge base or just want a robust CLI for your own scripts, this project has you covered.

Related MCP server: Roam Research MCP Server

How this differs from Roam's official MCP server

Roam Research ships its own MCP server and CLI (@roam-research/roam-mcp). It is a good tool, and this project is not trying to replace it. They talk to two different Roam APIs, which is the difference everything else follows from.

Reach for the official server when you want Roam's own supported path, or you need things only the running app can do: controlling the Desktop UI (open a page, read the current selection, drive the sidebar), semantic/embeddings search, link suggestions, file upload, comments, or invoking tools that Roam extensions register.

Reach for this one when Roam isn't running or isn't installed — a server, a container, a cron job, a CI step. Or when you want the extras this project has grown: a full standalone CLI with stdin piping, a shared HTTP daemon with optional bearer auth, smart page diffing that preserves block UIDs (and therefore your block references), batch operations with UID placeholders for building nested structures in one call, and agent memory tools.

One deliberate omission: there is no page-delete tool here. Roam has no undo that can reverse a bulk API deletion. The official server does offer delete_page; this project takes the more conservative line.

They interoperate

The two servers share conventions on purpose, so running both costs you nothing:

• [[roam/agent guidelines]] — both read the same page for your conventions. Write them once; both honour them. See Agent guidelines.

• #.rm-hide / #.rm-private — both withhold tagged blocks from AI-facing content. Tag once, hidden from both. See Hiding content from the AI.

Standalone CLI: roam

The roam CLI lets you interact with your graph directly from the terminal. It supports standard input (stdin) piping for all content creation and retrieval commands, making it perfect for automation workflows.

Quick Examples

# Save a quick thought to your daily page
roam save "Idea: A CLI for Roam would be cool"

# Pipe content from a file to a new page
cat meeting_notes.md | roam save --title "Meeting: Project Alpha"

# Create a TODO item on today's daily page
echo "Buy milk" | roam save --todo

# Prepend to top of page (newest-first ordering)
roam save -p "Changelog" --order first "v2.18.0 release"

# Search your graph and pipe results to another tool
roam search "important" --json | jq .

# Search for pages by namespace prefix
roam search --namespace "Convention"    # Finds all Convention/* pages

# Fetch a page by title
roam get "Roam Research"

# Fetch daily pages using any date format (auto-normalized)
roam get today                          # Today's daily page
roam get 2026-03-21                     # ISO date → "March 21st, 2026"
roam get "03/21/2026"                   # US date → "March 21st, 2026"
roam get "March 21"                     # Named (assumes current year)

# Fetch a block with ancestors (parent chain to page root)
roam get abc123def -a              # Block + children + ancestors
roam get abc123def -a -d 0         # Ancestors only, no children

# Fetch page by UID or Roam URL
roam get page abc123def
roam get page "https://roamresearch.com/#/app/my-graph/page/abc123def"

# Sort and group results
roam get --tag Project --sort created --group-by tag

# Find references (backlinks) to a page
roam refs "Project Alpha"

# Update a block (e.g., toggle TODO status)
roam update ((block-uid)) --todo

# Multi-graph: read from a specific graph
roam get "Page Title" -g work

# Multi-graph: write to a protected graph
roam save "Note" -g work --write-key "$ROAM_SYSTEM_WRITE_KEY"

Available Commands: get, search, save, refs, update, batch, rename, status, server. Run roam <command> --help for details on any command.

Installation

npm install -g roam-research-mcp
# The 'roam' command is now available globally

MCP Server Tools

The MCP server exposes these tools to AI assistants (like Claude), enabling them to read, write, and organize your Roam graph intelligently.

Multi-Graph Support: All tools accept optional graph and write_key parameters. Use graph to target a specific graph from your ROAM_GRAPHS config, and write_key for write operations on protected graphs.

Structured results from write tools (v3.0.0+)

The ten write tools declare an outputSchema and return structuredContent — a validated object — alongside the usual text. A client can read page_uid, uid_map or success directly instead of hunting for JSON inside a string, which makes chaining calls more reliable:

// roam_process_batch_actions
{ "success": true, "uid_map": { "parent1": "Xk7mN2pQ9" },
  "validation_passed": true, "actions_attempted": 4 }

Three things worth knowing:

• Nothing was taken away. The text channel is unchanged, so a client that ignores structuredContent behaves exactly as before.

• Read tools deliberately have neither. They already serialise their whole result into the text channel, so a schema would just double the payload.

• These fields are additive-only. Some clients validate live responses against a cached tool list, so a field will be added or deprecated — never renamed or removed outside a major version.

Upgrading from 2.x: three write-result fields were renamed — uid → page_uid (roam_create_page), created_uids → created_blocks (roam_create_outline, roam_import_markdown) and preservedUids → preserved_uids (roam_update_page_markdown). This only affects code that reads those names; if you use the server through an AI assistant, nothing changes. See the changelog for why.

Agent guidelines (per-graph)

roam_get_guidelines reads a page inside the graph — [[roam/agent guidelines]] by default — holding your own conventions: how you tag, how you namespace pages, what an agent should never do. Roam's official MCP server reads the same page title, so one page serves both.

This is distinct from CUSTOM_INSTRUCTIONS_PATH, and the two compose:

Just create the page. With no configuration at all, roam_get_guidelines reads [[roam/agent guidelines]] — the same title Roam's own server reads, so writing it once makes both honour it. Creating a page with that exact namespaced title is the opt-in; nothing is read from the graph unless an agent explicitly calls the tool.

If the page doesn't exist, the tool returns exists: false rather than failing, so it is always safe to call.

It also returns the rules that aren't yours to set

Alongside your conventions, every roam_get_guidelines response carries a roamSyntax field: the short list of things that destroy content — roam_update_page_markdown deleting every block your markdown omits, truncated structure previews written back as if they were content, block references retyped as plain text — plus a caution that reads silently exclude #.rm-hide subtrees, and the handful of places Roam's markdown inverts standard markdown.

Two reasons it rides here rather than in the cheatsheet. It reaches every client, including one that never calls roam_markdown_cheatsheet; and it is returned even when a graph has no guidelines page, which is exactly the case where an agent has least context. The layering is deliberate: your conventions win on style, roamSyntax wins on data safety. No convention can make a truncated preview complete.

The full syntax reference — components, queries, embeds, tool selection — stays in roam_markdown_cheatsheet. roamSyntax is ~800 tokens and deliberately capped.

Each graph can point at a different page, or turn it off:

ROAM_GRAPHS='{
  "personal": {"token": "...", "graph": "..."},
  "work":     {"token": "...", "graph": "...", "guidelinesPage": "work/agent rules"},
  "private":  {"token": "...", "graph": "...", "guidelinesPage": false}
}'
ROAM_GUIDELINES_PAGE='team/agent guidelines'   # change the default for every graph

Resolution order is per-graph guidelinesPage → ROAM_GUIDELINES_PAGE → roam/agent guidelines. Above: personal uses the env override, work uses its own page, and private has guidelines off entirely. Only an explicit false disables it — an unset value never does.

Results are cached for 30 seconds — an edit to the page takes effect without a restart. A starter template lives at .roam/agent-guidelines.template.md.

Note that guidelines are read through the normal page path, so blocks tagged #.rm-hide / #.rm-private are withheld from them too — see below.

Hiding content from the AI

Blocks tagged #.rm-hide or #.rm-private — and everything nested under them — are omitted from the content these tools return. Both the hashtag (#.rm-hide, #[[.rm-hide]]) and link ([[.rm-hide]]) forms work. .rm-private is Roam's existing "hidden from other users" tag; .rm-hide hides from the AI specifically.

This follows the same convention as Roam's official MCP server, so a block tagged for one is hidden from the other.

Applied to: roam_fetch_page_by_title, roam_fetch_block, roam_fetch_page_full_view, roam_get_subpages, roam_search_by_text, roam_search_for_tag, roam_search_by_status, roam_search_block_refs, roam_search_hierarchy, roam_search_by_date.

Hidden blocks are also excluded from the page-rewrite diff, which is what stops them being deleted for being absent from markdown the agent could not have written. roam_update_page_markdown (and roam save --update) replaces a page with what you give it, deleting whatever your markdown omits — so its baseline is pruned by this same filter, on the rule that the baseline a diff deletes from must be the same page the caller was allowed to read. It reports preserved_hidden when it protected anything. Content is preserved; exact ordering relative to visible siblings may shift. This was a real data-loss bug before the fix — see the changelog.

This is a convenience filter, not a security guarantee. roam_datomic_query reads the database directly and deliberately does not apply it, so a capable agent can still surface hidden blocks through raw Datalog. Treat these tags as "keep it out of the AI's way," not "keep it secret."

Tag matching is case-insensitive, and only exact tags match — #.rm-hidden and #.rm-highlight are left alone. The set of hidden UIDs is cached for 30 seconds, so a block tagged just now may remain visible for up to that long.

Configuration

Environment Variables

Single Graph Mode

For a single Roam graph, set these in your environment or a .env file:

ROAM_API_TOKEN=your-api-token
ROAM_GRAPH_NAME=your-graph-name

Multi-Graph Mode (v2.0+)

Connect to multiple Roam graphs from a single server instance:

ROAM_GRAPHS='{
  "personal": {"token": "token-1", "graph": "personal-db", "memoriesTag": "#[[Personal Memories]]"},
  "work": {"token": "token-2", "graph": "work-db", "protected": true, "memoriesTag": "#[[Work Memories]]"},
  "research": {"token": "token-3", "graph": "research-db"}
}'
ROAM_DEFAULT_GRAPH=personal
ROAM_SYSTEM_WRITE_KEY=your-secret-key

Graph Configuration Options:

Two kinds of access control (and how they differ)

The server has two independent locks. They're easy to mix up because both are "keys" — here's the plain version (both are optional and off by default):

Think of a house: the bearer token locks the front door (keeps strangers out entirely), and the write key locks a safe inside (even someone already in the house needs it to change what's in the safe). On your own machine bound to 127.0.0.1, the front door faces a wall — you don't need the bearer token there. The write key is still handy locally as an "are you sure?" guard, because Roam has no undo.

So: to mark a graph as needing the write key, set protected: true on it and configure ROAM_SYSTEM_WRITE_KEY; callers then pass a matching write_key for any write to that graph.

⚠️ protected does nothing on your default graph. Writes to whichever graph ROAM_DEFAULT_GRAPH names are always allowed, before protected is ever consulted — the flag guards the graphs you have to ask for by name, on the reasoning that reaching for a non-default graph is the deliberate act worth confirming. If you want a graph write-guarded, it must not be your default.

Optional:

• ROAM_MEMORIES_TAG: Default tag for roam_remember/roam_recall (fallback when per-graph memoriesTag not set).

• HTTP_STREAM_PORT: Port for the HTTP Stream transport (defaults to 8088). --server mode only — stdio mode opens no socket, so this is ignored there.

• HTTP_STREAM_HOST: Host to bind the HTTP transport to (defaults to 127.0.0.1, loopback-only). --server mode only. Set to 0.0.0.0 to expose on the LAN, and set HTTP_AUTH_TOKEN when you do.

• HTTP_AUTH_TOKEN: Optional bearer token that locks the whole HTTP endpoint. Unset = open (fine for loopback). When set, every MCP request must send Authorization: Bearer <token> (GET /health stays open). Use it whenever you bind beyond 127.0.0.1. Different from ROAM_SYSTEM_WRITE_KEY — see Two kinds of access control.

Running the Server

1. Default Mode (stdio) Best for local integration (e.g., Claude Desktop, IDE extensions). The MCP client launches the process per session and talks to it over stdin/stdout. No port is opened — nothing about MCP over stdio needs one.

Before 3.1.0 this mode also opened an HTTP listener, and bound it to every interface. If you were using that endpoint, run a --server daemon instead; see below.

npx roam-research-mcp

2. Shared Server Mode (--server) Best for a single long-lived, HTTP-only daemon that multiple MCP clients share — instead of each session spawning its own subprocess. This saves memory and gives clients a stable URL.

HTTP_STREAM_PORT=8088 npx roam-research-mcp --server

Or manage it through the roam CLI, which adds start/stop/status/logs:

roam server start            # start the shared daemon in the background
roam server start -H 0.0.0.0 # expose on the LAN (no transport auth!)
roam server status           # is it up? version, graphs, active sessions
roam server logs -f          # follow the log
roam server stop             # stop a CLI-started daemon

roam server status works no matter how the daemon was launched (it probes /health), so it also reports a daemon started by a LaunchAgent/systemd unit. State (pidfile + log) lives in ~/.roam/ (override with ROAM_HOME).

The two modes are mutually exclusive, and each opens exactly one transport: stdio mode speaks stdio and binds nothing, --server speaks HTTP and reads no stdin. In --server mode the server:

• runs HTTP-only (no stdio transport),

• binds the exact HTTP_STREAM_PORT on HTTP_STREAM_HOST and exits non-zero if the port is taken (no silent drift — a shared daemon must keep a stable URL),

• exposes GET /health → {"status":"ok", ...} for liveness checks.

Point MCP clients at it with an HTTP transport config:

{
  "mcpServers": {
    "roam-research-mcp": {
      "type": "http",
      "url": "http://127.0.0.1:8088/mcp"
    }
  }
}

Env vars (tokens, graphs) live with the server process, not the client config.

Securing an exposed server (two layers): If you bind beyond loopback (-H 0.0.0.0), add the perimeter lock:

HTTP_AUTH_TOKEN=$(openssl rand -hex 32) roam server start -H 0.0.0.0

Clients then send the token as a header:

{
  "mcpServers": {
    "roam-research-mcp": {
      "type": "http",
      "url": "http://<host>:8088/mcp",
      "headers": { "Authorization": "Bearer <token>" }
    }
  }
}

Keep both — they do different jobs (see Two kinds of access control above): the bearer token controls who can connect, the write key only guards writes to protected graphs.

⚠️ The write key is not a substitute for the bearer token. On an exposed server without HTTP_AUTH_TOKEN, anyone on the network can still read every graph (and write non-protected ones). For anything beyond loopback, set HTTP_AUTH_TOKEN.

Keeping it running (macOS LaunchAgent): Create ~/Library/LaunchAgents/com.example.roam-mcp.plist with RunAtLoad + KeepAlive, your env vars under EnvironmentVariables, and --server as the last ProgramArguments entry. Keep StandardOutPath/StandardErrorPath on a local path (e.g. ~/Library/Logs/), then:

launchctl bootstrap gui/$(id -u) ~/Library/LaunchAgents/com.example.roam-mcp.plist
curl -s http://127.0.0.1:8088/health   # verify

3. Docker

docker run -p 8088:8088 --env-file .env roam-research-mcp --server

Configuring in LLMs

Claude Desktop / Cline:

Add to your MCP settings file (e.g., ~/Library/Application Support/Claude/claude_desktop_config.json):

Pinning the version. npx -y roam-research-mcp fetches the latest release every time your client starts the server, so a new major version arrives without warning. Pin the major to decide for yourself when to move:

args	You get
["-y", "roam-research-mcp"]	Latest, always — including the next major
["-y", "roam-research-mcp@3"]	3.x only; majors need an edit here
["-y", "roam-research-mcp@3.0.0"]	Exactly this build

Pinning the major is the sensible default: you still get fixes and new tools, but a breaking change becomes something you opt into. The examples below stay unpinned to match what most people paste in first.

Single Graph:

{
  "mcpServers": {
    "roam-research": {
      "command": "npx",
      "args": ["-y", "roam-research-mcp"],
      "env": {
        "ROAM_API_TOKEN": "your-token",
        "ROAM_GRAPH_NAME": "your-graph"
      }
    }
  }
}

Multi-Graph:

{
  "mcpServers": {
    "roam-research": {
      "command": "npx",
      "args": ["-y", "roam-research-mcp"],
      "env": {
        "ROAM_GRAPHS": "{\"personal\":{\"token\":\"token-1\",\"graph\":\"personal-db\",\"memoriesTag\":\"#[[Memories]]\"},\"work\":{\"token\":\"token-2\",\"graph\":\"work-db\",\"protected\":true}}",
        "ROAM_DEFAULT_GRAPH": "personal",
        "ROAM_SYSTEM_WRITE_KEY": "your-secret-key"
      }
    }
  }
}

Query Block Parser (v2.11.0+)

A utility for parsing and executing Roam query blocks programmatically. Converts {{[[query]]: ...}} syntax into Datalog queries.

Supported Clauses

Relative Dates

The between clause supports relative dates: today, yesterday, last week, last month, this year, 7 days ago, 2 months ago, etc.

Usage

import { QueryExecutor } from 'roam-research-mcp/query';

const executor = new QueryExecutor(graph);

// Execute a query
const results = await executor.execute(
  '{{[[query]]: "My Query" {and: [[Project]] {between: [[last month]] [[today]]}}}}'
);

// Parse without executing (for debugging)
const { name, query } = QueryParser.parseWithName(queryBlock);

Utility Functions

import { isQueryBlock, extractQueryBlocks } from 'roam-research-mcp/query';

// Detect if text is a query block
isQueryBlock('{{[[query]]: [[tag]]}}'); // true

// Extract all query blocks from a string
extractQueryBlocks(pageContent); // ['{{[[query]]: ...}}', ...]

Support

If this project helps you manage your knowledge base or build cool agents, consider buying me a coffee! It helps keep the updates coming.

https://paypal.me/2b3/5

License

MIT License - Created by Ian Shen.
