GIMP MCP

Demo

Full demo (with audio): https://github.com/maorcc/gimp-mcp/raw/main/docs/demo.mp4

AI agent using GIMP MCP to remove a background, edit a character's expression, and verify results — all through natural language via Claude

Related MCP server: gemini-image-mcp-http

Overview

GIMP MCP bridges GIMP's professional image editing capabilities with AI assistants through the Model Context Protocol. It lets you edit images by describing what you want — and gives the AI a live visual feedback channel to verify each change before moving on.

What makes it different from other GIMP integrations:

• The AI can see the image at any point in the workflow without saving to disk (get_state_snapshot)

• Supports fully autonomous multi-step pipelines: open → edit → verify → refine → export

• 56 dedicated tool commands covering every major GIMP operation

• Fully compatible with GIMP 3.2.x (all breaking API changes resolved)

Key Features

What Can It Do?

Background Removal with Iterative Verification

The AI removes the background, takes a snapshot to inspect the result, detects remaining pixels, and loops until the image is clean:

"Remove the background from this image and keep looping until only the character remains"

Expression Editing

"Make the character smile — paint a smile arc with teeth over her mouth"

Complex Multi-Step Pipelines

"Open navi_portrait.png, remove the background, verify it's clean,
 then make her smile and export the final result as a PNG"

Color & Tone Work

"Boost the contrast, shift the hue 15 degrees warmer, then show me a before/after zoom of the face"

Text & Compositing

"Add a bold title at the top in white with a subtle drop shadow, then export for web"

Prerequisites

• GIMP 3.2+ — tested on GIMP 3.2.2 (Windows, macOS, Linux)

• Python 3.8+ — for the MCP server

• uv — Python package manager (pip install uv)

• MCP-compatible AI client — Claude Desktop, Claude Code, Gemini CLI, PydanticAI, etc.

Quick Start

1. Install Dependencies

git clone https://github.com/maorcc/gimp-mcp.git
cd gimp-mcp
uv sync

2. Install the GIMP Plugin

Copy gimp-mcp-plugin.py to GIMP's plug-ins directory and restart GIMP.

Which directory? GIMP names its per-user folder after its major.minor version (3.0, 3.2, 3.4, …) and creates a fresh one on each minor upgrade, so the folder moves when you upgrade GIMP (e.g. 3.0 → 3.2). The snippet below auto-selects the newest one, so it keeps working across upgrades. To check the path manually, open GIMP and look at Edit → Preferences → Folders → Plug-ins.

Launch GIMP at least once before running this, so its config folder exists.

macOS / Linux:

# Pick the base directory for your platform:
BASE="$HOME/Library/Application Support/GIMP"     # macOS
# BASE="$HOME/.config/GIMP"                        # Linux (standard)
# BASE="$HOME/snap/gimp/current/.config/GIMP"      # Linux (Snap)

# Auto-select the newest GIMP 3.x config directory (3.0, 3.2, 3.4, ...):
GIMP_DIR="$(ls -d "$BASE"/3.* 2>/dev/null | sort -V | tail -1)"
if [ -z "$GIMP_DIR" ]; then
  echo "No GIMP 3.x config dir found under $BASE — launch GIMP once, then re-run." >&2
  exit 1
fi
mkdir -p "$GIMP_DIR/plug-ins/gimp-mcp-plugin"
cp gimp-mcp-plugin.py "$GIMP_DIR/plug-ins/gimp-mcp-plugin/"
chmod +x "$GIMP_DIR/plug-ins/gimp-mcp-plugin/gimp-mcp-plugin.py"
echo "Installed into: $GIMP_DIR/plug-ins/gimp-mcp-plugin"

Windows:

%APPDATA%\GIMP\<VERSION>\plug-ins\gimp-mcp-plugin\gimp-mcp-plugin.py

Replace <VERSION> with your GIMP major.minor (e.g. 3.2). No chmod needed on Windows. Just copy and restart GIMP.

For all platforms: GIMP Plugin Installation Guide

3. Start the MCP Server in GIMP

1. Open any image in GIMP

2. Go to Tools > MCP > Start MCP Server

3. Server starts on localhost:9877

4. Configure Your MCP Client

Claude Desktop

~/.config/Claude/claude_desktop_config.json (Linux/macOS) or %APPDATA%\Claude\claude_desktop_config.json (Windows):

{
  "mcpServers": {
    "gimp": {
      "command": "uv",
      "args": ["run", "--directory", "/full/path/to/gimp-mcp", "gimp_mcp_server.py"]
    }
  }
}

Claude Code

cd /path/to/gimp-mcp
claude  # .mcp.json is auto-detected

Or manually:

claude mcp add gimp-mcp -- uv run --directory /full/path/to/gimp-mcp gimp_mcp_server.py

Gemini CLI

~/.config/gemini/.gemini_config.json:

{
  "mcpServers": {
    "gimp": {
      "command": "uv",
      "args": ["run", "--directory", "/full/path/to/gimp-mcp", "gimp_mcp_server.py"]
    }
  }
}

PydanticAI

from pydantic_ai import Agent
from pydantic_ai.mcp import MCPServerStdio

server = MCPServerStdio('uv', args=['run', '--directory', '/path/to/gimp-mcp', 'gimp_mcp_server.py'])
agent = Agent('openai:gpt-4o', mcp_servers=[server])

Available MCP Tools

👁️ Visual Feedback

get_state_snapshot(image_index, max_size, region, label)

Returns a live PNG of the current image state — the AI's primary feedback mechanism. Call this between any edits to verify the result without saving to disk.

# Full image snapshot
snapshot = get_state_snapshot(max_size=512)

# Zoom into a face region for detail inspection
snapshot = get_state_snapshot(
    region={"x": 140, "y": 80, "width": 240, "height": 300},
    max_size=512,
    label="face-check"
)

This enables iterative agentic workflows: edit → snapshot → assess → refine → repeat.

get_image_bitmap(image_index, max_width, max_height, region)

Lower-level bitmap fetch with region extraction and scaling. Returns base64-encoded PNG.

🎨 Adjustments

🔄 Transforms

✂️ Selections

🗂️ Layers

🖌️ Drawing & Fill

🔤 Text

✨ Filters & Effects

📁 File Operations

🔍 Info & Context

AI Agent Feedback Loop

The get_state_snapshot tool enables a pattern where the AI loops until a goal is visually confirmed:

┌─────────────┐
│  Apply edit │
└──────┬──────┘
       │
       ▼
┌─────────────────┐
│ get_state_      │  ← AI sees live PNG, no disk save needed
│ snapshot()      │
└──────┬──────────┘
       │
       ▼
┌─────────────────┐     ┌──────────────────┐
│ Goal achieved?  │─ No─▶ Adjust & retry   │
└──────┬──────────┘     └──────────────────┘
       │ Yes
       ▼
┌─────────────┐
│   Export    │
└─────────────┘

Example: Iterative Background Removal

See bg_remove_iterative.py for a complete example. The AI:

1. Removes the background using edge-seeded contiguous select

2. Takes a snapshot to check the result

3. Scans for remaining background-colored pixels

4. Runs targeted removal passes with progressively finer grids (25px → 1px)

5. Runs a final despeckle pass for isolated pixels

6. Loops until no background pixels remain

Example Scripts

Run the test suite to verify your setup:

python run_tests.py
# Expected: 56/56 PASSED

Technical Architecture

Plugin ↔ Server Communication

AI Client (Claude, etc.)
      │  MCP (stdio)
      ▼
gimp_mcp_server.py          ← MCP tool definitions
      │  TCP JSON  :9877
      ▼
gimp-mcp-plugin.py          ← Runs inside GIMP process
      │  PyGObject
      ▼
GIMP 3.2 (gi.repository.Gimp)

• MCP server translates tool calls into JSON commands sent to the plugin over TCP

• Plugin executes operations directly in the GIMP process via PyGObject

• Two message formats: {"type": "...", "params": {...}} for named tools, {"cmds": ["python..."]} for arbitrary exec

GIMP 3.2 Compatibility Notes

GIMP 3.x introduced breaking API changes from GIMP 2.x. Key fixes included in this release:

Troubleshooting

"Could not connect to GIMP"

• GIMP must be running with an image open

• Start the MCP server: Tools > Start MCP Server

• Check port 9877 is not blocked by firewall

Plugin Not Visible in GIMP

• Look under Tools > MCP (the plugin adds an MCP submenu, not a top-level Tools entry)

• Confirm the plugin file is in the correct directory (see install steps above)

• Upgraded GIMP recently? A minor upgrade (e.g. 3.0 → 3.2) moves the per-user config folder to a new version directory; reinstall the plugin into the new version's plug-ins folder. Verify the active path via Edit > Preferences > Folders > Plug-ins.

• On Linux/macOS: ensure the file has execute permission (chmod +x)

• Restart GIMP after installation

• Check Filters > Script-Fu > Console for error messages

Tests Failing

Run the test suite and check the failure list:

python run_tests.py

Each failure includes the tool name and error — most issues on GIMP 3.2 are covered by the fixes above.

Debug Mode

GIMP_MCP_DEBUG=1 uv run --directory /path/to/gimp-mcp gimp_mcp_server.py

Example Output

"Draw me a face and a sheep" — generated entirely through natural language via GIMP MCP

Future Enhancements

• 📚 Recipe Collection: Reusable workflow templates (portrait cleanup, product photo, etc.)

• ↩️ Undo System: History management and rollback via MCP

• 🚀 Dynamic Discovery: Auto-generate MCP tools from GIMP's full PDB procedure database

• 🔒 Security: Sandboxed execution for untrusted command inputs

• ⚡ Performance: Optimized bitmap transfer for large images

• 🌐 Remote Access: Network-accessible GIMP instances

Contributing

Contributions are welcome — bug fixes, new tools, documentation, or example scripts. Open a PR or issue on GitHub.

Development Setup

Install dev dependencies and activate the pre-commit hook so ruff runs on every commit:

uv sync
uv run pre-commit install

After this, ruff checks staged files on each git commit (with --fix applied automatically). The same check runs in CI, so the hook is just a fast local safety net.

To bump the pinned hook versions later:

uv run pre-commit autoupdate
