mcp-graphql-enhanced

An enhanced MCP (Model Context Protocol) server for GraphQL that fixes real-world interoperability issues between LLMs and GraphQL APIs.

Drop-in replacement for mcp-graphql — with dynamic headers, robust variables parsing, and zero breaking changes.

🎯 What is mcp-graphql-enhanced?

mcp-graphql-enhanced is a high-performance, federated GraphQL gateway designed to act as a workhorse for LLM agents. It bridges the gap between massive, complex GraphQL ecosystems and the context-limited environment of AI assistants. Unlike standard "all-or-nothing" introspection tools that crash under the weight of large schemas (like GitHub's or enterprise-grade Neo4j graphs), this server provides surgical control over how your agent perceives and interacts with your data.

💡 Why do you need it?

If you have ever seen the<error>Tool result is too large</error>while trying to introspect your API, you are already hitting the limits of standard MCP implementations. Here is why mcp-graphql-enhanced is the industry-standard choice for professional environments:

Avoid the 1MB Ceiling: It shifts the responsibility for scope from the server to the caller. Instead of a unilateral "everything or nothing" dump, you get granular control via typeNames and typeDepth parameters.

Surgical Precision: You can selectively introspect only the nodes you need (e.g., Repository, User, or Message), keeping your context window clean and your LLM focused.

Predictability over Immunity: It doesn't promise "unlimited" capacity—it promises predictability. In enterprise systems, you need a tool that lets you navigate the graph surgically and fail predictably if you overstep, rather than a "black box" that dies on you the moment the schema grows.

Proof of Performance: See a real-world demonstration of the gateway bypassing standard architectural limits during a live diagnostic test against the GitHub API: 🔗 Diagnostic Case Study: Scoped vs. Monolithic Introspection (Shared Chat)

💬 Community & Support

Join the conversation! If you have questions about using this bridge with Neo4j, Discord data graphs, or GraphQL in general, come hang out with us:

• Discord Channel: #mcp-graphql-enhanced

• Server: The official GraphQL Discord

This is the best place to share your feedback, report issues, or suggest new "enhanced" features for the bridge.

Related MCP server: mcp-graphql-schema

✨ Key Enhancements

• ✅ Dynamic Endpoint Switching — Hot-swap targets on the fly directly via tool arguments without restarting the server or losing session context.

• ✅ Built-in GraphiQL IDE — Visual playground at / (or /graphql, /graphiql) with pre-configured headers for instant testing and introspection.

• ✅ Dual Transport — Supports both STDIO (for local CLI/client tools) and HTTP/JSON-RPC (for external/browser clients).

• ✅ Dynamic headers — pass Authorization, X-API-Key, etc., via tool arguments (no config restarts)

• ✅ Robust variables parsing — fixes “Query variables must be a null or an object” error

• ✅ Smart introspection — supports filtered requests (via typeNames) and recursive depth control (via typeDepth) to minimize LLM context noise and optimize schema exploration.

• ✅ Full MCP compatibility — works with Claude Desktop, Groq Desktop, Google Antigravity, Glama, Gemini CLI, Hermes Agent and any standard MCP client

• ✅ Secure by default — mutations disabled unless explicitly enabled

• ✅ Dynamic Schema Evolution — Smart diagnostics and gap analysis for servers that regenerate GraphQL types on-the-fly (like Neo4j).

• ✅ Deep Observability — Automatic Cypher extraction and cleaning from GraphQL extensions.

🔥 Dynamic Endpoint Switching

The bridge allows LLMs or clients to dynamically target different GraphQL endpoints at runtime within a single session without requiring server restarts or configuration changes.

Simply pass the optional endpoint parameter in query-graphql or introspect-schema:

• Zero Downtime: Hot-swaps the underlying schema and clears internal caches instantly.

• Context Preservation: Keeps the MCP connection open while shifting queries between different environments (e.g., switching from a Discord ingest node to a Neo4j graph database).

🚀 Federated Multi-Node Architecture (v3.9.1+)

The server operates as a Federated GraphQL Gateway, merging independent nodes into a unified system.

• Zero Breaking Changes: If you provide a single URL in ENDPOINT, the server behaves exactly as before.

• Federated Introspection: Scans all endpoints simultaneously to build a global capability map.

• Smart Aggregation: When multiple comma-separated URLs are provided, the server broadcasts queries and merges results using universal deep deduplication (object-level).

• Conflict Handling: Identifies structural differences in identical Type names across nodes and exposes them uniquely.

• Bypass Free Tier Limits: Perfect for users of "Free Tier" cloud databases (like Neo4j Aura). You can split your data across multiple free instances and use this bridge to query them as a single unified graph, effectively bypassing entity count limitations.

Proof of Concept:

See a real-world demonstration of the federated query synthesis in action, where the agent aggregates live Discord data with historical Neo4j insights: 🔗 Live Federation Analysis (Shared Chat)

💡 Use Case: Bridging WSL and Windows (PowerShell)

A common challenge for Windows developers is the network isolation between the Windows Subsystem for Linux (WSL) and the host OS. This feature allows you to bridge these two worlds into a "Unified Nervous System".

Example configuration for Claude Desktop:

{
  "ENDPOINT": "http://DESKTOP-NAME.local:2311/graphql,http://127.0.0.1:4000/graphql"
}

• Hybrid Ecosystem: Seamlessly query and aggregate data across Windows-native processes (PowerShell) and Linux-based environments (WSL).

• mDNS Support: By using .local addresses, the bridge automatically resolves the host machine's IP from within the WSL environment.

• Transparent Aggregation: The AI assistant interacts with a single unified schema, unaware that the data is being fetched from different operating systems simultaneously.

🔍 Advanced Observability & Cypher

The bridge provides deep insights into how the LLM interacts with your graph database.

🕸️ Automated Cypher Extraction

For GraphQL server implementations that return query execution plans (like @neo4j/graphql), the bridge automatically:

1. Detects extensions.cypher in the response.

2. Sanitizes the output by stripping internal headers (like CYPHER 5 or empty PARAMS).

3. Injects a clean Cypher block directly into the tool's output for the AI to analyze.

Note: This feature requires your GraphQL server to be configured to include debug information in the response extensions.

🎨 Visual Command Center (GraphiQL)

Unlike standard MCP servers, this one provides a visual interface for humans. When running with ENABLE_HTTP=true, you can open a full-featured GraphiQL IDE in your browser.

• Endpoint: http://localhost:6274/ (or /graphql, /graphiql)

• Header Sync: Any headers set in your environment (like GitHub tokens) are automatically injected into the GraphiQL "Headers" tab for immediate testing.

💻 HTTP / Dual Transport

This server now runs in dual transport mode, supporting both the standard STDIO communication (used by most MCP clients) and a new HTTP JSON-RPC endpoint on port 6274.

This allows external systems, web applications, and direct curl commands to access the server's tools with live request logging in your terminal ([HTTP-RPC] logs).

Automatic Port Selection

The server defaults to port 6274. If you encounter an EADDRINUSE error, the server will automatically find the next available port. Check the server logs for the final bound port (e.g., [HTTP] Started server on http://localhost:6275).

Resolving Port Conflicts (EADDRINUSE) and Automatic Port Selection

The server defaults to port 6274. If you encounter an EADDRINUSE: address already in use :::6274 error (common in local development due to stale processes), the server will automatically find the next available port (up to 10 attempts, not spawning multiple servers).

This ensures the server starts successfully even when the default is blocked. Always check the server logs for the final bound port (e.g., [HTTP] Started server on http://localhost:6275) if your curl or client tool fails on the default 6274.

To force a specific port (e.g., for guaranteed external firewall settings), you can still explicitly set the MCP_PORT environment variable:

Testing the HTTP Endpoint

You can test the endpoint using curl as long as the server is running (e.g., via npm run dev):

Test the health check (assuming the server bound to the default or found the next available port)

curl http://localhost:6274/health

Testing the JSON-RPC Transport

curl -X POST http://localhost:6274/mcp  \
-H "Content-Type: application/json"  \
-d '{
  "jsonrpc":"2.0",
  "method":"tools/list",
  "params":{},
  "id":1
}'

curl -X POST http://localhost:6274/mcp \
-H "Content-Type: application/json" \
-d '{
  "jsonrpc": "2.0",
  "method": "tools/call",
  "params": {
    "name": "introspect-schema",
    "arguments": {}
  },
  "id": 2
}'

curl -X POST http://localhost:6274/mcp \
-H "Content-Type: application/json" \
-d '{
  "jsonrpc": "2.0",
  "method": "tools/call",
  "params": {
    "name": "introspect-schema",
    "arguments": {
      "endpoint": "https://mcp-neo4j-discord.vercel.app/api/graphiql"
    }
  },
  "id": 3
}'

curl -X POST http://localhost:6274/mcp \
-H "Content-Type: application/json" \
-d '{
  "jsonrpc": "2.0",
  "method": "tools/call",
  "params": {
    "name": "introspect-schema",
    "arguments": {
      "typeNames": ["User", "Message"]
    }
  },
  "id": 4
}'

curl -X POST http://localhost:6274/mcp \
-H "Content-Type: application/json" \
-d '{
  "jsonrpc": "2.0",
  "method": "tools/call",
  "params": {
    "name": "introspect-schema",
    "arguments": {
      "typeNames": ["Message"],
      "typeDepth": 4
    }
  },
  "id": 5
}'

curl -X POST http://localhost:6274/mcp \
  -H "Content-Type: application/json" \
  -d '{
    "jsonrpc": "2.0",
    "method": "tools/call",
    "params": {
      "name": "query-graphql",
      "arguments": {
        "query": "{ guildChannels(guild_id: \"1312302100125843476\") { name id topic } }"
      }
    },
    "id": 6
  }'

# Executing query with dynamic endpoint switching
curl -X POST http://localhost:6274/mcp \
  -H "Content-Type: application/json" \
  -d '{
    "jsonrpc": "2.0",
    "method": "tools/call",
    "params": {
      "name": "query-graphql",
      "arguments": {
        "endpoint": "https://mcp-neo4j-discord.vercel.app/api/graphiql",
        "query": "{ getGuilds { name } }"
      }
    },
    "id": 7
  }'

# Targeted introspection with depth control and dynamic endpoint switching
curl -X POST http://localhost:6274/mcp \
  -H "Content-Type: application/json" \
  -d '{
    "jsonrpc": "2.0",
    "method": "tools/call",
    "params": {
      "name": "introspect-schema",
      "arguments": {
        "endpoint": "https://mcp-neo4j-discord.vercel.app/api/graphiql",
        "typeNames": ["Message"],
        "typeDepth": 1
      }
    },
    "id": 8
  }'

(using port 6275 if 6274 was busy)

curl -X POST http://localhost:6275/mcp -H "Content-Type: application/json" -d '{"jsonrpc":"2.0","method":"query-graphql","params":{"query":"query { __typename }"},"id":1}'

🔍 Use the official MCP Inspector to test your server live:

npx @modelcontextprotocol/inspector \
  -e ENDPOINT=https://api.example.com/graphql \
  npx @letoribo/mcp-graphql-enhanced

Environment Variables (Breaking change in 1.0.0)

Note: As of version 1.0.0, command line arguments have been replaced with environment variables.

• auto (default): Automatically enables HTTP only when running in MCP Inspector...

• true: Always enable HTTP server

• false: Disable HTTP server completely

🚀 Examples

1. Quick Start

Basic startup using the default endpoint.

npx @letoribo/mcp-graphql-enhanced

2. Configuration & Authentication

Running with custom headers (e.g., for API keys or Bearer tokens).

ENDPOINT=https://api.example.com/graphql \
HEADERS='{"Authorization":"Bearer xyz"}' \
npx @letoribo/mcp-graphql-enhanced

3. Advanced Integration

Using a local .graphql file If you want to work with a local schema without querying the API directly.

ENDPOINT=http://localhost:3000/graphql \
SCHEMA=./schema.graphql \
npx @letoribo/mcp-graphql-enhanced

Enabling Mutations (Writes) Mutations are disabled by default for security. To enable them:

ENDPOINT=http://localhost:3000/graphql \
ALLOW_MUTATIONS=true \
npx @letoribo/mcp-graphql-enhanced

Multi-Node Architecture (Federation) Aggregating data from multiple sources into a single unified graph.

ENDPOINT=https://mcp-discord.vercel.app/api/graphiql,https://mcp-neo4j-discord.vercel.app/api/graphiql \
npx @letoribo/mcp-graphql-enhanced

4. Customizing Environment

Example of port configuration and development mode settings.

# Change the HTTP port
MCP_PORT=8080 npx @letoribo/mcp-graphql-enhanced

# Test targeted introspection and explore the schema visually:
ENDPOINT=https://api.github.com/graphql \
HEADERS='{"Authorization":"Bearer YOUR_GITHUB_TOKEN"}' \
ENABLE_HTTP=true \
npx @letoribo/mcp-graphql-enhanced

# Then visit http://localhost:6274/graphiql

5. Interactive Launch with mcpgql (Recommended)

If you want to skip manual environment variable setup, use our CLI tool available on npm. If installed globally (npm install -g @letoribo/mcpgql), simply run:

mcpgql

Alternatively, you can run it without global installation using:

npx @letoribo/mcpgql@latest

• Zero-config start: Automatic discovery and template initialization.

• Interactive selection: Toggle multiple endpoints and permissions on the fly.

• Bridge mode: Automatically handles the Federated Bridge setup on localhost:6274.

6. Integration via Smithery CLI

Smithery provides a powerful way to manage your MCP servers, handle authentication, and interact with tools directly from your terminal

# 1. Install Smithery CLI
npm install -g smithery

# 2. Create a namespace
smithery namespace create {your-namespace}

# 3. Add the server
smithery mcp add letoribo/mcp-graphql-enhanced

# 4. Interact with tools
smithery tool list {connection}
smithery tool call {connection} {tool_name} '{"key": "value"}'

E.g.
smithery tool call letoribo-mcp-graphql-enhanced introspect-schema
smithery tool call letoribo-mcp-graphql-enhanced introspect-schema '{"typeNames": ["Guild", "Message", "User"]}'
smithery tool call letoribo-mcp-graphql-enhanced introspect-schema '{"typeNames": ["McpServer"], "typeDepth": 2}'
smithery tool call letoribo-mcp-graphql-enhanced introspect-schema '{"endpoint": "https://mcp-discord.vercel.app/api/graphiql"}'
smithery tool call letoribo-mcp-graphql-enhanced query-graphql '{"query": "{ countMcpServers }"}'
smithery tool call letoribo-mcp-graphql-enhanced query-graphql '{"query": "{ countMcpServers(q: \"graphql\") }"}'
smithery tool call letoribo-mcp-graphql-enhanced query-graphql '{"query": "{ proxyInfo { host source timestamp } }"}'
smithery tool call letoribo-mcp-graphql-enhanced query-graphql '{"query": "{ guildChannels(guild_id: \"1312302100125843476\") { name id topic } }"}'
smithery tool call letoribo-mcp-graphql-enhanced query-graphql '{"query": "{ searchMcpServers(q: \"mcp-remote\", limit: 50) { id name namespace description environmentVariablesJsonSchema { properties required } } }"}'
smithery tool call letoribo-mcp-graphql-enhanced query-graphql '{"query": "{ getMcpServer(id: \"a17sht5lzn\") { name namespace description environmentVariablesJsonSchema { properties required } repository { url } slug spdxLicense { name url } tools { description inputSchema name } url attributes id }}"}'
smithery tool call letoribo-mcp-graphql-enhanced query-graphql '{"endpoint": "https://mcp-neo4j-discord.vercel.app/api/graphiql", "query": "{ getGuilds { name } }"}'

☁️ Deploy to Cloud

This server is fully containerized and optimized for long-running processes.

Recommended Hosting

Important:

• For hosted environments, you must set the environment variable ENABLE_HTTP=true in your platform's settings to ensure the HTTP transport layer is active.

• Ensure your hosting provider's public networking settings are configured to route traffic to the port defined in your PORT environment variable to avoid 502 Bad Gateway errors.

⚠️ Concurrent Cloud Usage & Dynamic Endpoints

While mcp-graphql-enhanced supports switching target endpoints on the fly via the optional endpoint argument, keep state mutability in mind when running in hosted/shared environments (e.g., Render, Railway, Smithery):

• State Isolation: Providing an endpoint argument dynamically updates the active graph context for the server instance.

• Best Practice for Concurrent Cloud Requests: If multiple clients, agent sessions, or automated workers share the same cloud instance, always pass the endpoint explicitly in every tool call (query-graphql and introspect-schema).

• Preventing Context Drift: Relying on the implicitly cached endpoint in a shared environment can lead to race conditions where a concurrent call from another session switches the active upstream URL under your feet.

🌐 Public Live Gateways (Hosted SSE/HTTP Bridges)

If you want to test the bridge instantly without running local Node.js processes, use our hosted cloud endpoints:

Note: Public gateways operate in shared environments. Remember to supply your explicit endpoint and headers in tool calls to ensure request isolation.

🖥️ Claude Desktop Configuration Examples

You can connect Claude Desktop to your GraphQL API using either the npx package (recommended for simplicity) or the Docker image (ideal for reproducibility and isolation).

✅ Option 1: Using npx

{
  "mcpServers": {
    "mcp-graphql-enhanced": {
      "command": "npx",
      "args": ["@letoribo/mcp-graphql-enhanced"],
      "env": {
        "ENDPOINT": "https://your-api.com/graphql"
      }
    }
  }
}

🐳 Option 2: Using Docker (auto-pull supported)

{
  "mcpServers": {
    "mcp-graphql-enhanced": {
      "command": "sh",
      "args": [
        "-c",
        "docker run --rm -i -e ENDPOINT=$ENDPOINT -e HEADERS=$HEADERS -e ALLOW_MUTATIONS=$ALLOW_MUTATIONS ghcr.io/letoribo/mcp-graphql-enhanced:main"
      ],
      "env": {
        "ENDPOINT": "https://your-api.com/graphql",
        "HEADERS": "{\"Authorization\": \"Bearer YOUR_TOKEN\"}",
        "ALLOW_MUTATIONS": "false"
      }
    }
  }
}

🧪 Option 3: Using node with local build (for development)

If you’ve cloned the repo and built the project (npm run build → outputs to dist/):

{
  "mcpServers": {
    "mcp-graphql-enhanced": {
      "command": "node",
      "args": ["dist/index.js"],
      "env": {
        "ENDPOINT": "https://your-api.com/graphql",
        "ALLOW_MUTATIONS": "true"
      }
    }
  }
}

Resources

• graphql-schema: The server exposes the GraphQL schema as a resource that clients can access. This is either the local schema file, a schema file hosted at a URL, or based on an introspection query.

Available Tools

The server provides two main tools:

1. introspect-schema: Retrieves the GraphQL schema or a subset. Use this first to understand the graph structure.

• Arguments:

  • typeNames (optional, array): List of specific types to introspect (e.g., ["User", "Message"]). Reduces noise by returning only relevant parts of the graph.

  • typeDepth (optional, number): Controls the recursion level of nested fields (Default: 2).

    Note: typeDepth is only functional when typeNames is provided to narrow the scope.

  • endpoint (optional, string): Target GraphQL HTTP/HTTPS URL to dynamically switch endpoint on the fly before executing introspection.

  • headers (optional, string): JSON stringified object of custom HTTP headers (e.g., '{"Authorization": "Bearer token"}').

• Note: Filtered introspection is only available when querying a live GraphQL endpoint.

2. query-graphql: Execute GraphQL queries against the endpoint. By default, mutations are disabled unless ALLOW_MUTATIONS is set to true.

• Arguments:

  • query (required, string): The GraphQL query or mutation string.

  • variables (optional, string): JSON stringified object of variables.

  • endpoint (optional, string): Target GraphQL HTTP/HTTPS URL to dynamically switch endpoint on the fly before executing query.

  • headers (optional, string): JSON stringified object of custom HTTP headers (e.g., '{"Authorization": "Bearer token"}').

💡 Note: Dynamic Headers vs Static env Previously, auth tokens had to be hardcoded statically at startup inside the configuration's "env" block (e.g., in claude_desktop_config.json).

With the optional headers argument added directly to query-graphql and introspect-schema, you get total dynamic control:

• Keep Secrets in Your Terminal: You don't have to feed your private tokens (like GitHub PATs or Bearer keys) directly into Claude's prompt or static setup. Just set "ENABLE_HTTP": "true", run your cURL commands or local scripts directly in the terminal, and pass headers there. Any headers passed at runtime will override static tokens from your config file. Otherwise, Claude might just laugh at you for sharing your raw secret tokens in the chat!

• On-the-Fly Switching: You can dynamically inject different auth headers per request or per endpoint right at execution time without restarting the MCP server.

Security Considerations

Mutations are disabled by default to prevent unintended data changes. Always validate HEADERS and SCHEMA inputs in production. Use HTTPS endpoints and short-lived tokens where possible.

Customize for your own server

This is a very generic implementation where it allows for complete introspection and for your users to do whatever (including mutations). If you need a more specific implementation I'd suggest to just create your own MCP and lock down tool calling for clients to only input specific query fields and/or variables. You can use this as a reference.
