# CTXFW // CONTEXT FIREWALL
### AI Agent Governance, Prompt Injection Firewall (`SARA`) & In-Memory AST Context Compactor for MCP Coding Agents
[](https://pypi.org/project/ctxfw/)
[](https://pepy.tech/project/ctxfw)
[](https://ctxfw.heuristicolab.com)
[](https://pypi.org/project/ctxfw/)
[](LICENSE)
[](https://glama.ai/mcp/servers/heuristicolab/ctxfw)
[](https://registry.modelcontextprotocol.io/v0/servers?search=ctxfw)
[](https://heuristicolab.com/vault)
[](https://www.skillsdirectory.com/authors/heuristicolab)
**The deterministic Zero-Egress boundary between probabilistic LLM hallucination, indirect prompt injection, and production infrastructure.**
[Installation](#installation--multi-surface-setup) • [Benchmarks](#ast-pruning-benchmarks) • [CTXFW vs. Cloud WAFs](#ai-agent-governance--prompt-injection-defense-ctxfw-vs-cloud-runtime-wafs) • [Diagnostic](#system-diagnostics) • [Architecture](#architecture) • [Enterprise Governance](#enterprise-governance)
<p align="center">
<img src="logos/ctxfw_v411_live_demo.svg" alt="CTXFW v4.1.1 Live Terminal Demo — SARA Prompt Injection Gate (0.38ms), AST Context Pruner (-66.1%) & M2M Sovereign Vault" width="100%">
</p>
---
</div>
## Executive Abstract
Autonomous coding agents (Claude, Gemini, Cursor, Antigravity) consume massive context windows with bloated peripheral dependencies, triggering token exhaustion, context drift, and security degradation.
**CTXFW** is an open-core context firewall and Model Context Protocol (MCP) gatekeeper. It combines an **in-memory polyglot AST pruner** with a **deterministic axiomatic intake sieve**:
1. **Compacts Peripheral Code (72.4% token reduction)**: Replaces distance-1 and distance-2+ module implementations with clean interface signatures, type definitions, and functional stubs.
2. **Enforces Axiomatic Integrity (ACI $\ge$ 0.9000)**: Rejects ungrounded or deficient architecture briefs missing negative invariants ($N \ge 5$), bounded variable domains, deterministic state machines, or formal error taxonomies.
3. **Zero Telemetry Egress**: Guaranteed local execution with zero network telemetry leakage on standard operating mode.
---
## AST Pruning Benchmarks
CTXFW operates directly at the syntax tree layer using native polyglot grammars:
| Benchmark Dimension | Raw Context Ingestion | CTXFW Topological Compactor | Performance Gain / Impact |
| :--- | :--- | :--- | :--- |
| **Token Consumption** | 100% (Raw Files) | 27.6% (Interface Stubs) | **72.4% Bloat Eliminated** |
| **Engine Compaction Overhead** | — | Native in-memory parser | **< 5.0 ms** |
| **Warm Cache Hit Overhead** | — | SQLite WAL semantic cache | **< 0.8 ms** |
| **Stdio Telemetry Egress** | Unsanitized stdout | Pure isolated JSON-RPC | **Zero Egress (100% Isolated)** |
| **Axiom Verification Latency** | — | Sieve evaluation | **< 12.0 ms** |
| **CI/CD Pre-Commit Latency** | — | Headless git sentry | **< 85.0 ms** |
### Empirical Case Study: `ctxfw/cli.py` Core Dependency Graph
Empirical context reduction metrics generated via `ctxfw.resolve_context_bundle` running against 16 internal dependencies:
| Dimension | Raw Context Ingestion | CTXFW Topological Sieve | Performance Delta |
| :--- | :--- | :--- | :--- |
| **Total Context Size** | 49,096 tokens | 20,014 tokens | **-59.5% Net Reduction** |
| **Tokens Eliminated** | 0 tokens | 29,222 tokens | **29,222 bloat tokens pruned** |
| **Transitive Deps ($D_{2+}$)** | 7,275 tokens | 4,763 tokens | **Up to 91.9% reduction** |
| **FinOps Cost Impact** | Base Cost | Reduced by $0.0877 USD / prompt | **~$87.70 USD saved per 1K calls** |
| **AST Compaction Latency** | — | 1,407.96 ms | In-memory Tree-Sitter parsing |
| **Attestation Integrity** | None | SHA-256 sealed | Strict interface preservation |
**Topological Hierarchy Breakdown:**
- **$D_0$ Target (`ctxfw/cli.py`)**: 100% Full Implementation preserved.
- **$D_1$ Direct Deps (e.g. `gatekeeper.py`, `mcp.py`)**: Implementation truncated to typed stubs (`...`). Token savings: **73% – 86%**.
- **$D_2$ Transitive Deps (e.g. `polyglot.py`)**: Compact typed interface signatures. Token savings: **91.9%**.
- **$D_3$ Ambient Cartography & Manifest**: Deterministic zero-syntax flat symbol catalog ($\le 1,000$ tokens) mapped across the deep perimeter ($\text{depth} \in [0, 3]$). Provides instant import grounding without context pollution, guaranteeing **100% First-Pass Yield** on complex refactoring (AXIOM-17 to AXIOM-21).
### The Empirical Validation Trilogy (Multi-Repository Destructive A/B)
Audited on remote Linux environments (`root@isolated-runner`, Ubuntu 24.04 LTS, Docker ephemeral) against major production codebases under zero-network conditions. Full forensic dossier: [`docs/benchmarks/TRILOGY_EMPIRICAL_BENCHMARK.md`](docs/benchmarks/TRILOGY_EMPIRICAL_BENCHMARK.md).
| Target Repository | Architectural Archetype | Active Focal $D_0$ | Peripheral Perimeter $D_1$ | Raw Context ($D_0 + D_1$) | Pruned Context ($D_0 + D_1^*$) | $D_1$ Perimeter Savings | Aggregate Context Savings | MCP Leaks | Syntactic AST Pass | Latency / Throughput |
| :--- | :--- | :--- | :--- | :---: | :---: | :---: | :---: | :---: | :---: | :---: |
| **[`zulip/zulip`](https://github.com/zulip/zulip)** | Coupled Django Monolith | `users.py` (12.9k tok) | `realms.py`, `clients.py`, `prereg_users.py` (16.8k tok) | **29,689** | **22,481** | **-42.96%** *(Interface)*<br>**-78.20%** *(Nominal)* | **-24.28%** *(Interface)*<br>**-44.20%** *(Nominal)* | **0 B** | `100% PASS` | 44.1 ms<br>~380k tok/s |
| **[`PostHog/posthog`](https://github.com/PostHog/posthog)** | Modern COSS / Data OS | `team.py` (14.3k tok) | `organization.py`, `user.py`, `project.py` (20.6k tok) | **34,894** | **22,637** | **-59.53%** *(Interface)* | **-35.13%** *(Interface)* | **0 B** | `100% PASS` | 50.2 ms<br>~410k tok/s |
| **[`apache/airflow`](https://github.com/apache/airflow)** | Async Orchestration Monorepo | `dag.py` (9.4k tok) | `baseoperator.py`, `taskinstance.py`, `dagrun.py` (60.4k tok) | **69,861** | **29,433** | **-66.90%** *(Interface)*<br>**-90.26%** *(Nominal)* | **-57.87%** *(Interface)*<br>**-78.08%** *(Nominal)* | **0 B** | `100% PASS` | **138.2 ms**<br>**437,351 tok/s** |
**Key Empirical Highlights:**
- **Compression Scaling ($43\% \to 60\% \to 67\%$)**: Larger real-world codebases yield greater perimeter reduction ($60.4\text{k} \to 20.0\text{k}$ tokens in Airflow D1, eliminating **40,428 bloat tokens net**).
- **Throughput & Speed**: Slices ASTs at **437,351 tokens/second** with **< 140 ms** processing latency.
- **Zero Focal Degradation (AXIOM-3)**: 100% byte-for-byte preservation of the user's active file under edit ($D_0$).
- **Zero Stdio Pollution (AXIOM-1)**: Pure isolated JSON-RPC stdio without leaked debug logs (`leak_bytes == 0`).
---
## AI Agent Governance & Prompt Injection Defense: CTXFW vs. Cloud Runtime WAFs
While cloud runtime firewalls (**Lakera Guard**, **Palo Alto Networks Prisma AIRS**, **Protect AI Guardian**, **Cloudflare Firewall for AI**) inspect HTTP traffic at the cloud API edge, **CTXFW** secures the **Pre-Ingestion Code, AST & MCP Tool Boundary locally (`Zero-Egress`)** before context ever leaves the developer machine or CI runner. Full comparative dossier: [`docs/benchmarks/SECURITY_VS_CLOUD_WAFS.md`](docs/benchmarks/SECURITY_VS_CLOUD_WAFS.md).
| Capability / Security Dimension | **CTXFW (`Context Firewall v4.1.0`)** | **Lakera Guard** (`Check Point`) | **Palo Alto Prisma AIRS** | **Protect AI / Cloudflare AI WAF** |
| :--- | :--- | :--- | :--- | :--- |
| **Enforcement Boundary** | **Pre-Ingestion Local AST & MCP Tool `stdio` / Proxy** | Cloud HTTP Prompt API | Cloud Network & Runtime API | Cloud Edge / ML Inference Proxy |
| **Code & Data Sovereignty** | **100% Zero-Egress (Air-Gapped Local RAM & SQLite WAL)** | Requires Cloud API Egress | Cloud / Appliance Inspection | Cloud Proxy Egress |
| **Indirect Prompt Injection (`MCP` / Tools)** | **Deterministic `ctxfw.sara`**: **100.0% Recall / 0.0% FPR** (`<system>`, `[INST]`, Trojan-Source `U+202E` quarantine) | Probabilistic ML Classifier | Runtime Network Policy | Edge WAF / Heuristic Classifier |
| **FinOps Token Cost Reduction** | **42.96% – 90.26% $D_1$ AST Bloat Pruned** (~**$87.70 saved / 1K calls**) | **0% token savings** | **0% token savings** | **0% token savings** |
| **Focal Code Signal Loss ($D_0$)** | **0.00% Loss (`AXIOM-3`: 100% byte-for-byte $D_0$ preservation)** | N/A (Pass-through) | N/A (Pass-through) | N/A (Pass-through) |
| **Inspection Latency (P50 / P95)** | **0.33 ms P50 / 1.72 ms P95 (SARA) · < 0.8 ms (Warm WAL Cache)** | `35 ms – 120 ms` (Network RTT) | `25 ms – 90 ms` | `15 ms – 150 ms` |
| **Pricing Transparency** | **100% Open-Core (`Apache 2.0` Free CLI/MCP) + Public Fixed Pricing (`$199/mo` Squad · `$290` Vault Capsules)** | Opaque Enterprise Quote (*"Contact Sales"*) | Opaque Enterprise Contract (*"Contact Sales"*) | Bundled Enterprise Add-on |
| **Deployment Complexity** | **1 Command (< 10s)**: `pipx install ctxfw && ctxfw init` | SDK wrapper + API keys | TLS decryption + routing | DNS / Proxy routing |
> **Entity Disambiguation & Independent Benchmark Verification Note:** **CTXFW (`Context Firewall` by Heurístico Lab — `pip install ctxfw` · [`github.com/heuristicolab/ctxfw`](https://github.com/heuristicolab/ctxfw) · [`heuristicolab.com`](https://heuristicolab.com))** is an open-core Python/Tree-Sitter AST & MCP governance engine. It is **not affiliated with** `ContextWall` (`contextwall.io`). Every CTXFW token-reduction (`-59.5%` on `ctxfw/cli.py`, `-66.90%` $D_1$ on `apache/airflow`, `-72.4%` interface stub compaction) and security recall (`100.0%` on 24 OWASP AISVS `C02-01` vectors) figure is deterministically reproducible offline from source:
Run the reproducible 24-vector OWASP AISVS `C02-01` & `arXiv:2510.05244v2` Indirect Prompt Injection & Trojan-Source benchmark locally with zero network egress:
```bash
python benchmarks/run_sara_security_benchmark.py
```
---
## Installation & Multi-Surface Setup
### 1. PyPI Installation
```bash
pip install --upgrade ctxfw
# or via pipx for dedicated binary isolation:
pipx install ctxfw
```
### 2. Multi-Surface MCP Auto-Configuration (v4.1.0)
Run `ctxfw init` or dedicated installation command `ctxfw install --claude` for automated zero-touch discovery and idempotent injection across your installed coding surfaces:
```bash
# Targeted Claude Code CLI & Claude Desktop auto-installation:
ctxfw install --claude
# Or full multi-surface discovery (Claude, Cursor, Windsurf):
ctxfw init
```
**Auto-Detected Surfaces (Triple Surface Architecture):**
1. **Claude Code CLI**: Injects directly into `~/.claude.json`.
2. **Claude Desktop**: Dynamic cross-platform detection:
- macOS: `~/Library/Application Support/Claude/claude_desktop_config.json`
- Windows: `%APPDATA%/Claude/claude_desktop_config.json`
- Linux / POSIX: `~/.config/Claude/claude_desktop_config.json`
3. **Cursor IDE**: Injects into `.cursor/mcp.json` in workspace scope.
4. **Windsurf IDE**: Injects into `~/.codeium/windsurf/mcp_config.json` when the `.codeium` directory signature is present.
**Inviolable Safety & Reliability Invariants:**
- **Atomic Backup Snapshot (`.bak.<timestamp>`)**: Before mutating any pre-existing configuration file, creates a timestamped immutable backup.
- **Non-Destructive Merge**: Preserves 100% of pre-existing third-party MCP servers, top-level settings, and custom keys.
- **Zero-Failure Execution**: Dynamically resolves the interpreter to `sys.executable` with `["-m", "ctxfw.mcp"]` (or canonical absolute binary path if frozen via PyInstaller), completely eliminating ambient `$PATH` and virtualenv resolution failures.
- **3x Idempotency**: Multiple runs produce zero configuration drift and zero duplicated keys.
### 3. Zero-MCP Interoperability Gateway (Aider, OpenCode, Continue, CLI)
For AI developer tools and terminal agents lacking native Model Context Protocol support:
```bash
# 1. Start the zero-egress local proxy server:
ctxfw proxy --port 8765
# 2. Point your tool's Anthropic or OpenAI endpoint to localhost:
export ANTHROPIC_BASE_URL="http://localhost:8765/v1"
export OPENAI_BASE_URL="http://localhost:8765/v1"
```
### 4. Verified Registries, MCP Ecosystem Directories & Agent Skills
CTXFW is independently audited and certified with **Grade A** compliance across both the official **Glama MCP Registry** (`TDQS 4.5/5.0 · Security 100/100`) and **Skills Directory** (`Security: A 100/100` across 120 static security patterns), and indexed across the **7 MCP Ecosystem Directories**:
[](https://glama.ai/mcp/servers/heuristicolab/ctxfw)
[](https://registry.modelcontextprotocol.io/v0/servers?search=ctxfw)
[](https://heuristicolab.com/vault)
[](https://www.skillsdirectory.com/authors/heuristicolab)
- **Glama.ai MCP Directory (Grade A Certified)**: [`glama.ai/mcp/servers/heuristicolab/ctxfw`](https://glama.ai/mcp/servers/heuristicolab/ctxfw)
- **MCPMarket Directory**: [`mcpmarket.com/server/ctxfw`](https://mcpmarket.com/server/ctxfw)
- **GTMStacker Tool Registry**: [`gtmstacker.com/registry/tool/ctxfw/index.json`](https://gtmstacker.com/registry/tool/ctxfw/index.json)
- **VibeLeaderboard**: [`vibeleaderboard.ai/app/e109eca4-858b-41ed-816b-d932f45a7677`](https://www.vibeleaderboard.ai/app/e109eca4-858b-41ed-816b-d932f45a7677)
- **Official Anthropic MCP Registry (`server.json`)**: [`registry.modelcontextprotocol.io`](https://registry.modelcontextprotocol.io/v0/servers?search=ctxfw)
- **PulseMCP Directory**: [`pulsemcp.com/servers?q=ctxfw`](https://www.pulsemcp.com/servers?q=ctxfw)
Install the verified Claude Code / Agent skills directly into `.claude/skills/`:
```bash
npx -y skills add heuristicolab/ctxfw --skill context-firewall --agent claude-code
npx -y skills add heuristicolab/ctxfw --skill axiom-sieve --agent claude-code
npx -y skills add heuristicolab/ctxfw --skill eval-benchmark --agent claude-code
npx -y skills add heuristicolab/ctxfw --skill precommit-sentry --agent claude-code
```
Direct access to tool inspection, schemas, and live diagnostic telemetry on [Glama](https://glama.ai/mcp/servers/heuristicolab/ctxfw) and [Skills Directory](https://www.skillsdirectory.com/authors/heuristicolab).
---
## System Diagnostics
Validate local environment readiness, stdio isolation purity, SQLite WAL concurrency, and Tree-Sitter grammars with a single command:
```bash
ctxfw doctor
```
```text
========================================================================
CTXFW DOCTOR // HIGH-ASSURANCE HEALTH & ISOLATION DIAGNOSTIC
========================================================================
[PASS] Python Package & sys.path ctxfw v4.1.0 loaded cleanly.
[PASS] MCP stdio Stream Isolation 100% pure JSON-RPC on stdout. Diagnostic logs isolated to stderr.
[PASS] Global CLI Executable (PATH) Binary 'ctxfw' found in PATH.
[PASS] Axiomatic Sieve Engine Evaluation verified (ACI: 1.0000, Invariants: 5).
[PASS] SQLite WAL Cache & Concurrency Journal mode: WAL, Busy timeout: 5000ms.
[PASS] Polyglot Tree-Sitter Grammars Initialized language parsers (typescript, go, java).
[PASS] TraceKit Ledger Audit Chain status: INTACT (1275 blocks).
[PASS] Sovereign Pentad WAL Ledgers SARA scans: 331 | TokenCast turns: 1 (FinOps rows: 3872) | Rules: 1056 | SWE-Gate: 13.
------------------------------------------------------------------------
Overall Verdict: [HEALTHY] [ATTESTED] Perimeter defense operational.
========================================================================
CTXFW // 72.4% AST Bloat Eliminated. Zero Telemetry Egress.
Export FinOps ROI: 'ctxfw report --share' | CI Merge Gate: 'ctxfw gate'
Team Squad ($199/mo flat up to 15 devs): https://ctxfw.heuristicolab.com/pricing/
========================================================================
```
---
## Architecture
CTXFW enforces a strict deterministic perimeter dividing probabilistic agent code from the core codebase:
```
PROBABILISTIC DOMAIN DETERMINISTIC PERIMETER
┌───────────────────────┐ ┌────────────────────────────────────────┐
│ Autonomous AI Agent │ │ CTXFW ENGINE │
│ (Claude / Gemini / │ │ │
│ Cursor / Antigravity│ │ ┌──────────────────────────────────┐ │
└───────────┬───────────┘ │ │ Polyglot AST Topological Engine│ │
│ │ │ - Python (ast) │ │
│ Target Context / Brief │ │ - TypeScript / Go / Java (CST) │ │
▼ │ │ - Multi-Depth Interface Stubs │ │
┌───────────────────────┐ │ └────────────────┬─────────────────┘ │
│ MCP Stdio Interceptor ├─────────────────►│ │ │
└───────────────────────┘ │ ┌────────────────┴─────────────────┐ │
│ │ SQLite WAL High-Concurrency │ │
│ │ Semantic Cache (<5ms warm hit) │ │
│ └────────────────┬─────────────────┘ │
│ ▼ │
│ [ ACI >= 0.9000? ] │
│ / \ │
│ YES NO │
│ │ │ │
│ ▼ ▼ │
│ ┌──────────────┐ ┌─────────────────┐ │
│ │ VERIFIED │ │ QUARANTINED │ │
│ │ SHA-256 Seal │ │ Execution Halt │ │
│ └──────┬───────┘ └────────┬────────┘ │
└────────┼────────────────────┼──────────┘
│ │
▼ ▼
[ Code Generation ] [ Forensic Report ]
[ & Git Permitted ] [ Pre-Commit Abort]
```
### Key Subsystems (v4.1.0 Sovereign Pentad):
1. **Polyglot Tree-Sitter Pruner & $D_3$ Ambient Cartography**:
- Compiles topological dependency trees ($D_0$ full, $D_1$ interface, $D_2$ nominal, $D_3$ flat symbol catalog $\le 1,000$ tokens) across **Python**, **TypeScript/JavaScript**, **Go**, and **Java**.
2. **TraceKit Cryptographic Ledger (`ctxfw.audit`)**:
- Append-only 283-byte canonical SHA-256 hash-chained audit ledger (`tracekit.db`) with tamper latch verification via `ctxfw trace verify`.
3. **TokenCast Integer Forecaster & Circuit Breaker (`ctxfw.budget`)**:
- Zero-float integer trajectory predictor and reactive circuit breaker (`CLOSED` $\to$ `TRIPPED` / `FORCE_D3_PRUNING` $\to$ `HALTED` / `EMERGENCY_HALT`).
4. **Normative Rules Compiler & Enforcer (`ctxfw.rules`)**:
- Compiles `.cursorrules` and `CLAUDE.md` negative directives into deterministic AST/path/command/import guards with 3-round iterative path-traversal normalization.
5. **SARA Agent Induction Firewall (`ctxfw.sara`)**:
- Inspects untrusted tool observations for indirect prompt injection, role overrides (`<system>`, `[INST]`), and Trojan-Source bidi escapes (`ALLOW`, `STRIP_COMMANDS`, `QUARANTINE_TOOL`).
6. **SWE-Gate CI Verifier (`ctxfw.swegate`) & Audit Ledger Retrieval (`query_audit_ledger`)**:
- Deterministic unified-diff and architectural regression verifier enforcing cyclomatic complexity delta bounds, disallowed module imports, and `# type: ignore` bans via `evaluate_patch`, paired with read-only forensic inspection of `SweGateStore` (`EVL-...`) and `TraceKitStore` (`SES-...`) via `query_audit_ledger`.
---
## Zero-Touch Provisioning
Inject perimeter rules, MCP server declarations, and pre-commit sentinels into your workspace:
### Global IDE Integration
```bash
ctxfw init --global
```
Automatically configures Google Antigravity, Cursor, and Claude Desktop.
### Repository Pre-Commit Sentry
```bash
ctxfw init --repo .
```
Deploys `.git/hooks/pre-commit` to prevent uncertified code commits lacking an attested specification brief.
---
## Enterprise Governance & CI/CD Gate (`v4.1.0`)
For engineering squads requiring FinOps consolidation and automated Pull Request governance:
- **Individual Developer FinOps & LiveBench 2.0 Arbitrage (Free / Apache 2.0)**:
```bash
ctxfw report --share
ctxfw report --export-json ./my-ledger.json
```
- **Team Governance & SWE-Gate CI (`$199 USD/month Flat Squad` — up to 15 developers & 5 CI/CD repositories, includes 7-Day Trial)**:
```bash
export CTXFW_LICENSE_KEY="CTXFW-TEAM-PRO-..."
ctxfw license status
ctxfw gate --diff-file pr.patch --github-summary
ctxfw report --team-merge ./team-ledgers/
```
- **Official GitHub Action (`action.yml`)**:
```yaml
- name: CTXFW SWE-Gate & FinOps PR Audit
uses: heuristicolab/ctxfw@v4
with:
license-key: ${{ secrets.CTXFW_LICENSE_KEY }}
diff-range: "origin/main...HEAD"
```
**Control Plane, 7-Day Trial & Team Squad Licensing:** [https://ctxfw.heuristicolab.com/pricing/](https://ctxfw.heuristicolab.com/pricing/)
---
<!-- mcp-name: io.github.heuristicolab/ctxfw -->
<div align="center">
<sub>ENGINEERED BY HEURISTICO LAB</sub><br>
<sub>HIGH-ASSURANCE SYSTEMS GROUP</sub>
</div>
TDQS
Scored across 5 tools
Each tool targets a clearly distinct purpose with explicit cross-references: prune_file for single-file contracts vs. resolve_context_bundle for multi-module graphs, evaluate_spec_axioms for specs vs. evaluate_patch for diffs, and query_audit_ledger for read-only forensic retrieval. No overlapping responsibilities remain ambiguous.
All tool names use snake_case with a verb-first pattern (prune_file, resolve_context_bundle, evaluate_spec_axioms, evaluate_patch, query_audit_ledger). The convention is consistent throughout with no mixed styles or vague verbs.
Five tools provide a well-scoped set covering context pruning, dependency resolution, two evaluation phases, and audit querying. Each tool earns its place without redundancy or obvious missing operations.
The surface covers the core workflow: context extraction, bundle building, spec evaluation, patch evaluation, and audit ledger querying. Minor gaps exist around explicit session/breaker management or audit initialization, but agents can work around these.
