<p align="center">
  <img src="https://raw.githubusercontent.com/ed-smartass/esmole-mcp/main/assets/esmole-logo.png" alt="esmole mascot" width="160">
</p>

<h1 align="center">esmole-mcp</h1>

<p align="center">
  <b>Elasticsearch 7.x and 8.x for AI agents that manage their own connections: add, edit and remove clusters through MCP tools at runtime, per project, hot-reloaded, through SSH.</b>
</p>

<p align="center">
  <a href="https://www.npmjs.com/package/esmole-mcp"><img src="https://img.shields.io/npm/v/esmole-mcp" alt="npm version"></a>
  <a href="https://www.npmjs.com/package/esmole-mcp"><img src="https://img.shields.io/npm/dm/esmole-mcp" alt="npm downloads"></a>
  <a href="https://github.com/ed-smartass/esmole-mcp/actions/workflows/ci.yml"><img src="https://github.com/ed-smartass/esmole-mcp/actions/workflows/ci.yml/badge.svg" alt="CI"></a>
  <a href="https://github.com/ed-smartass/esmole-mcp/blob/main/LICENSE"><img src="https://img.shields.io/npm/l/esmole-mcp" alt="MIT license"></a>
</p>

esmole-mcp is a stdio [MCP](https://modelcontextprotocol.io) server for Elasticsearch. Tell
your agent "connect to the logs cluster through bastion.example.com, readonly" and it calls
`add_connection`. The connection lands in a per-project `.esmole.json` or in your global store,
and both are re-read on every tool call, so a change made by the agent, by you in an editor,
or by another session applies on the next call. No client config edits, no restarts.

- Elasticsearch 7.x and 8.x, any number of named clusters, API key or basic auth.
- SSH tunnels with password, key or agent auth; host keys verified against `known_hosts` or a
  pinned fingerprint.
- `readonly` connections limited to an allowlist of read endpoints, absolute request
  timeouts, a 10 MB response cap, and results capped at 40 KB so a big aggregation cannot
  flood the context.

Need PostgreSQL or MySQL? [dbmole-mcp](https://github.com/ed-smartass/dbmole-mcp) is the same
design for SQL databases.

## Demo

![The agent adds a readonly cluster to the project and searches it](https://raw.githubusercontent.com/ed-smartass/esmole-mcp/main/assets/esmole-demo.gif)

## Install

Requires Node.js 22 or newer. The server needs no configuration to start; connections are
added later.

**Claude Code**

```bash
claude mcp add esmole -- npx -y esmole-mcp
```

Add `--scope user` to enable it in every project. Or install it as a plugin (Claude Code
2.1.275 or later):

```text
/plugin install esmole --marketplace ed-smartass/esmole-mcp
```

**Codex**

```bash
codex mcp add esmole -- npx -y esmole-mcp
```

or in `~/.codex/config.toml`:

```toml
[mcp_servers.esmole]
command = "npx"
args = ["-y", "esmole-mcp"]
```

**Cursor**

[![Add esmole to Cursor](https://cursor.com/deeplink/mcp-install-dark.svg)](https://cursor.com/install-mcp?name=esmole&config=eyJjb21tYW5kIjoibnB4IiwiYXJncyI6WyIteSIsImVzbW9sZS1tY3AiXX0%3D)

**VS Code**

[![Install in VS Code](https://img.shields.io/badge/VS_Code-Install_Server-0098FF?style=flat-square&logo=visualstudiocode&logoColor=white)](https://insiders.vscode.dev/redirect/mcp/install?name=esmole&config=%7B%22command%22%3A%22npx%22%2C%22args%22%3A%5B%22-y%22%2C%22esmole-mcp%22%5D%7D)

**Claude Desktop**

Download `esmole-mcp-<version>.mcpb` from the
[latest release](https://github.com/ed-smartass/esmole-mcp/releases/latest) and open it, or add
the JSON below to `claude_desktop_config.json`. Claude Desktop does not start servers inside a
project, so keep connections in the global store (the default scope).

**Any other MCP client**

```json
{
    "mcpServers": {
        "esmole": { "command": "npx", "args": ["-y", "esmole-mcp"] }
    }
}
```

**Docker**

The image is built from source:

```bash
git clone https://github.com/ed-smartass/esmole-mcp.git && cd esmole-mcp
docker build -t esmole-mcp .
```

```json
{
    "mcpServers": {
        "esmole": {
            "command": "docker",
            "args": [
                "run", "-i", "--rm",
                "-v", "esmole-store:/home/node/.config/esmole",
                "-v", "/abs/path/to/project:/work",
                "-v", "/home/me/.ssh/known_hosts:/home/node/.ssh/known_hosts:ro",
                "esmole-mcp"
            ]
        }
    }
}
```

The container runs as `node` with cwd `/work`: mount a project there to use its
`.esmole.json`, and the named volume keeps the global store. Mount `known_hosts` for SSH
connections (or pin `ssh.hostKey`), and any private key you reference by `privateKeyPath`, at
the path the connection names; for `ssh.agent: true`, forward the agent socket
(`-v "$SSH_AUTH_SOCK:/ssh-agent" -e SSH_AUTH_SOCK=/ssh-agent`). To reach hosts that only your machine can reach, add
`--add-host=host.docker.internal:host-gateway` (Linux) and use `host.docker.internal`. The
image has no `git`, so the "not ignored by git" check always warns.

A 0.1 setup that still sets `ESMOLE_CONNECTIONS`, `ESMOLE_CONFIG` or `--config` starts fine:
the server prints one line on stderr saying they are ignored. See the
[changelog](https://github.com/ed-smartass/esmole-mcp/blob/main/CHANGELOG.md#migrating-from-01).

## Quick start

Ask the agent, for example:

> Add a readonly elasticsearch connection `logs` to this project: https on 10.0.0.20, API key
> VnVhQ2ZH…, through ssh as deploy@bastion.example.com with my ssh agent. Then show the five
> biggest indices.

It calls `add_connection` with:

```json
{
    "name": "logs",
    "host": "10.0.0.20",
    "apiKey": "VnVhQ2ZH…",
    "readonly": true,
    "ssh": { "host": "bastion.example.com", "user": "deploy", "agent": true },
    "scope": "project"
}
```

then `test_connection` and `es_list_indices`. Credentials you type in chat pass through the
model's context; for production secrets, write the entry into the file yourself.

## Connections

### Two layers

| Layer | File | Shape |
| --- | --- | --- |
| `project` | `.esmole.json`, found from the server's working directory | `{ "connections": [ ... ] }` |
| `global` | `~/.config/esmole/connections.json`, or the path in `ESMOLE_STORE` | `[ ... ]` |

- **Same name in both: the project entry wins.** `list_connections` reports each connection's
  `source` (`project` or `global`) and, when it hides an entry of the same name in the other
  layer, `shadows`.
- **Hot reload.** Both files are re-read on every tool call. Edit a file mid-session and the next
  call uses the new settings; a changed connection gets a fresh client, the old one is closed.
- **Project file discovery.** Starting from the server's working directory (Claude Code and
  Codex start it in the project directory), esmole walks up to the filesystem root and uses
  the first `.esmole.json` it finds. In a linked git worktree with no file of its own, it falls
  back to the main checkout's `.esmole.json`, so every worktree of a repo shares one file.
- Both files are plain JSON with mode `0600`, written atomically. Writes keep entries they
  cannot parse verbatim, and refuse to overwrite a file that is not valid JSON.

### Managing connections with tools

- `add_connection` takes the connection fields plus `scope`: `"global"` (default) or
  `"project"`. With `project` and no file yet, the file is created at the main checkout root
  (or the git root, or the working directory outside git). If git does not ignore it, the
  response warns you; add `.esmole.json` to `.gitignore` so credentials are not committed.
- `add_connection` fails when the name already exists in the target layer. The same name in
  the other layer is allowed; the response says which entry now shadows which.
- `update_connection` patches the connection where it lives (the winning layer). A `null`
  value removes an optional field. An `ssh` object is merged into the stored one field by
  field, so `{ "ssh": { "hostKey": "SHA256:..." } }` keeps the stored SSH secrets.
- `remove_connection` deletes it from that layer and tells you if that uncovers a same-name
  entry in the other layer.
- Credentials are never echoed back: `list_connections` shows scheme, host, port, the auth
  kind, `verifyTls`, `readonly`, `source` and whether SSH is used.

### Broken and invalid entries

- An entry that fails validation does not silently disappear: its name resolves to an error
  (`connection 'x' in <file> is invalid: ...`) instead of falling through to a same-name entry
  in the global store, and `list_connections` lists it as invalid. A name defined twice in one
  file is an error too. `remove_connection` can delete an invalid entry.
- A file that exists but is unreadable, not JSON, or the wrong shape is reported in
  `list_connections` (`brokenLayers`). A broken project file blocks every connection; a broken
  global store blocks only names the project file does not define. A missing file is just
  empty.

### Connection fields

Unknown fields are rejected. Authentication is required: an `apiKey`, or both `user` and
`password`.

| Field | Type | Notes |
| --- | --- | --- |
| `name` | string | `[a-zA-Z0-9_-]+` |
| `type` | `elasticsearch` | default `elasticsearch` |
| `host` | string | as seen from the SSH bastion when `ssh` is set |
| `port` | number | default `9200` |
| `scheme` | `http` \| `https` | default `https` |
| `verifyTls` | boolean | default `true`; `false` skips certificate verification |
| `apiKey` | string | API key (the base64 `id:key` form) |
| `user`, `password` | string | basic auth |
| `readonly` | boolean | default `false`, see [Readonly](#readonly) |
| `queryTimeoutMs` | integer | milliseconds, default `60000`, at most `2147483647`; see [Limits and timeouts](#limits-and-timeouts) |
| `ssh` | object | see [SSH tunnels](#ssh-tunnels) |

Example `.esmole.json`:

```json
{
    "connections": [
        { "name": "local", "host": "localhost", "scheme": "http", "user": "elastic", "password": "changeme" },
        {
            "name": "logs",
            "host": "10.0.0.20",
            "apiKey": "VnVhQ2ZHY0JDZGJrUW0t...",
            "readonly": true,
            "ssh": { "host": "bastion.example.com", "user": "deploy", "agent": true }
        }
    ]
}
```

## SSH tunnels

| `ssh` field | Notes |
| --- | --- |
| `host`, `port` | bastion; port defaults to `22` |
| `user` | SSH user |
| `password` | password auth |
| `privateKey` / `privateKeyPath` | key contents, or a path (`~` is expanded) |
| `passphrase` | for an encrypted key |
| `agent` | `true` to use the agent at `SSH_AUTH_SOCK` |
| `hostKey` | pinned host key fingerprint, `SHA256:...` (OpenSSH format) |

```json
{ "host": "bastion.example.com", "user": "deploy", "privateKeyPath": "~/.ssh/id_ed25519" }
{ "host": "bastion.example.com", "user": "deploy", "password": "…" }
{ "host": "bastion.example.com", "port": 2222, "user": "deploy", "agent": true }
{ "host": "bastion.example.com", "user": "deploy", "agent": true, "hostKey": "SHA256:EXAMPLEexampleEXAMPLEexampleEXAMPLEexample1" }
```

**Host keys are verified.** With `hostKey` set, the bastion's key must match it (trailing `=`
padding is accepted) and `known_hosts` is not consulted. Otherwise the key must match an entry
for the host in `~/.ssh/known_hosts` (`host` on port 22, `[host]:port` otherwise):

- Plain and hashed host names match. Wildcard patterns never match, and a line with a negated
  wildcard (`!*.example.com`) is ignored.
- A key listed under `@revoked` is rejected for every host, whatever the line's host pattern.
  `@cert-authority` lines and unknown markers are skipped.

There is no trust-on-first-use: an unknown key fails the connection with an error that shows
the presented fingerprint. Check it against a trusted source, then either add the host to
`known_hosts` or pin it:

```bash
ssh-keyscan -p 22 bastion.example.com 2>/dev/null | ssh-keygen -lf -
# 256 SHA256:EXAMPLEexampleEXAMPLEexampleEXAMPLEexample1 bastion.example.com (ED25519)
```

and ask the agent to `update_connection` with `ssh.hostKey` set to that `SHA256:...` value.

Tunnels send keepalives every 15 s and are rebuilt after 3 missed replies. Not supported:
`ProxyJump` and `~/.ssh/config`, SSH certificates. With `scheme: "https"` through a tunnel,
the certificate is checked against `host`, not the tunnel's local address.

## Readonly

`readonly: true` protects against accidental writes. Every tool, `es_request` included,
checks method and path against an allowlist before anything is sent:

- `GET` and `HEAD`: allowed.
- `POST`: only `_search`, `_msearch`, `_count`, `_field_caps` and `_pit` (optionally under one
  index or pattern, e.g. `/logs-*/_search`), and `/_search/scroll`.
- `DELETE`: only `/_search/scroll` and `/_pit` (closing read sessions).
- Everything else is refused, as is any path containing `..`, `%2e`, `%2f`, `%5c`, `\` or
  `#`, whatever the method. So on a readonly connection `es_request` cannot use date-math
  index names with `/` rounding, such as `<logs-{now/d}>`; writable connections are not
  affected.
- Index and pattern arguments of the helper tools are validated too (no `/`, `\`, `?`, `#`,
  `%`, whitespace, `..`); comma lists, wildcards, `-exclusions` and `cluster:index` work.
  Date-math names need `%`-encoding, so they only work through `es_request`.
- Because every `GET` passes, GET-only maintenance endpoints such as `GET /_flush` pass too.
  They change no documents, but they are not reads.

It is **not a security boundary**: the agent can switch it off with `update_connection`, by
design. For a hard guarantee, use an Elasticsearch role or API key with read privileges only.

## Tools

| Tool | What it does |
| --- | --- |
| `list_connections` | connections with their `source`, shadowed names, invalid entries and broken files |
| `add_connection` | add a connection to the `project` file or the `global` store |
| `update_connection` | patch a connection where it lives; `null` removes a field |
| `remove_connection` | remove a connection; reports a same-name entry it uncovers |
| `test_connection` | connect end to end (including the tunnel) and report cluster version and latency |
| `es_request` | any method, path, body and query params; readonly-guarded; a string body for NDJSON (`_bulk`, `_msearch`) |
| `es_search` | `query`, `aggs`, `size`, `source` (sent as `_source`), `sort`, `from`, `search_after`, `track_total_hits`, `highlight`, `script_fields` on an index or pattern; a whole body nested into `query` is lifted, with a `note` |
| `es_list_indices` | indices matching a pattern (default `*`) with health, doc count and store size |
| `es_get_mapping` | mapping flattened to `field: type`; `raw: true` for the original |
| `es_cluster_health` | cluster health |

`es_search` `size` defaults to 10 and is capped at 1000, also when it comes from a nested
body; with `aggs` and no `query` it is 0. Tool arguments are checked strictly: a wrong key is
rejected with a hint, e.g. `unknown key '_source' — did you mean 'source'?`.

A 4xx or 5xx from the cluster, `es_request` included, comes back as a tool error:
`HTTP <status> <root_cause[0].type>: <reason>` on the first line, then the trimmed response
body. `test_connection` fails on any non-2xx answer (e.g. 401 from a secured cluster).

The ten tool definitions cost about 2.1k tokens of context (`tools/list` is about 8,200
characters; measured with `npm run smoke`, at roughly 4 characters per token).

## Limits and timeouts

- Every result is at most 40 KB of JSON. Strings longer than 2 KB are cut and marked
  `…[+N bytes]`; if the body still does not fit, its longest array (hits, buckets) is halved
  until it does. The result says so in `truncated` and stays valid JSON. Ask for less with
  `size` and `source` on `es_search`, or `filter_path` on `es_request`.
- Responses larger than 10 MB are aborted with an error ("narrow it with size/_source"),
  never returned partially.
- `queryTimeoutMs` (default 60 s) is an absolute deadline per request, from connecting to
  reading the last byte of the body.

## How it compares

| | esmole-mcp | [elastic/mcp-server-elasticsearch](https://github.com/elastic/mcp-server-elasticsearch) | [cr7258/elasticsearch-mcp-server](https://github.com/cr7258/elasticsearch-mcp-server) |
| --- | --- | --- | --- |
| Status | maintained | deprecated; Elastic points to the Agent Builder MCP endpoint (Elasticsearch 9.2+) | maintained |
| Elasticsearch 7.x | ✓ | — | ✓ |
| Elasticsearch 8.x | ✓ | ✓ | ✓ |
| OpenSearch | — | ✗ | ✓ |
| SSH tunnel built in | ✓ | ✗ | ✗ |
| Agent adds and edits connections through MCP tools | ✓ | ✗ | ✗ |

✓ documented, ✗ not offered, — not mentioned or not tested. Checked October 2026; corrections
welcome.

## Security

Connection files hold plaintext credentials (mode `0600`). Keep `.esmole.json` out of git.
Cluster errors are passed to the client verbatim.

Whoever can change a connection, through `update_connection` or by editing a connection file,
can redirect its credentials. Changing `host` keeps the stored password or API key, and
changing `ssh.host` keeps the stored SSH password or key, so the next call sends them to the
new host. Treat write access to the connection tools and files like access to the credentials.

A project's `.esmole.json` is trusted as is: in a cloned or untrusted repository it can add
connections or shadow a global one of the same name and send your queries to another host.
Discovery walks up to `/`, so a file in a parent directory (such as `~`) applies to every
project below it. Check `list_connections` before working in an unfamiliar repository.

Each open SSH tunnel listens on `127.0.0.1` at a random port without authentication: while it
is open, any local process, including other users on a shared host, can connect through it
to the target host. The cluster still asks for its own credentials.

See [SECURITY.md](https://github.com/ed-smartass/esmole-mcp/blob/main/SECURITY.md) for the
threat model and how to report a vulnerability.

## Development

```bash
npm ci
npm run lint        # Biome
npm run typecheck   # tsc
npm run test:unit   # unit tests, mocked IO
npm run test:int    # integration tests against Elasticsearch 7.17 and 8.x (needs Docker)
npm run smoke       # build, npm pack, install the tarball in a temp dir, boot, tools/list
```

The shared connection core is [`@dbmole/core`](https://github.com/ed-smartass/dbmole-mcp/tree/main/packages/core),
developed in the dbmole-mcp repo and bundled into this package at build time. See
[CONTRIBUTING.md](https://github.com/ed-smartass/esmole-mcp/blob/main/CONTRIBUTING.md).

## License

[MIT](https://github.com/ed-smartass/esmole-mcp/blob/main/LICENSE)

This server cannot be deployed

One endpoint for every MCP toolRayrun runs every MCP server behind one URL and holds the credentials. Each call is decided per client, tool, and argument, then recorded.ray.runAd

Maintenance

ActivityNo data
ResponsivenessNo issues

Resources
