<h1 align="center">dbmole-mcp</h1>
<p align="center">
<b>PostgreSQL and MySQL for AI agents that manage their own connections: add, edit and remove them through MCP tools at runtime, per project, hot-reloaded, through SSH.</b>
</p>
<p align="center">
<a href="https://www.npmjs.com/package/dbmole-mcp"><img src="https://img.shields.io/npm/v/dbmole-mcp" alt="npm version"></a>
<a href="https://www.npmjs.com/package/dbmole-mcp"><img src="https://img.shields.io/npm/dm/dbmole-mcp" alt="npm downloads"></a>
<a href="https://github.com/ed-smartass/dbmole-mcp/actions/workflows/ci.yml"><img src="https://github.com/ed-smartass/dbmole-mcp/actions/workflows/ci.yml/badge.svg" alt="CI"></a>
<a href="https://github.com/ed-smartass/dbmole-mcp/blob/main/LICENSE"><img src="https://img.shields.io/npm/l/dbmole-mcp" alt="MIT license"></a>
</p>
dbmole-mcp is a stdio [MCP](https://modelcontextprotocol.io) server. Tell your agent "connect
to the staging replica through bastion.example.com, readonly" and it calls `add_connection`.
The connection lands in a per-project `.dbmole.json` or in your global store, and both are
re-read on every tool call, so a change made by the agent, by you in an editor, or by another
session applies on the next call. No client config edits, no restarts.
- One server for PostgreSQL and MySQL, any number of named connections.
- SSH tunnels with password, key or agent auth; host keys verified against `known_hosts` or a
pinned fingerprint.
- TLS with full certificate and hostname verification, also through the tunnel.
- `readonly` connections enforced by the database session, per-call timeouts, results capped
at 40 KB so a wide `SELECT *` cannot flood the context.
Need Elasticsearch? [esmole-mcp](https://github.com/ed-smartass/esmole-mcp) is the same design
for Elasticsearch 7.x and 8.x.
## Demo
## Install
Requires Node.js 22 or newer. The server needs no configuration to start; connections are
added later.
**Claude Code**
```bash
claude mcp add dbmole -- npx -y dbmole-mcp
```
Add `--scope user` to enable it in every project. Or install it as a plugin (Claude Code
2.1.275 or later):
```text
/plugin install dbmole --marketplace ed-smartass/dbmole-mcp
```
**Codex**
```bash
codex mcp add dbmole -- npx -y dbmole-mcp
```
or in `~/.codex/config.toml`:
```toml
[mcp_servers.dbmole]
command = "npx"
args = ["-y", "dbmole-mcp"]
```
**Cursor**
[](https://cursor.com/install-mcp?name=dbmole&config=eyJjb21tYW5kIjoibnB4IiwiYXJncyI6WyIteSIsImRibW9sZS1tY3AiXX0%3D)
**VS Code**
[](https://insiders.vscode.dev/redirect/mcp/install?name=dbmole&config=%7B%22command%22%3A%22npx%22%2C%22args%22%3A%5B%22-y%22%2C%22dbmole-mcp%22%5D%7D)
**Claude Desktop**
Download `dbmole-mcp-<version>.mcpb` from the
[latest release](https://github.com/ed-smartass/dbmole-mcp/releases/latest) and open it, or add
the JSON below to `claude_desktop_config.json`. Claude Desktop does not start servers inside a
project, so keep connections in the global store (the default scope).
**Any other MCP client**
```json
{
"mcpServers": {
"dbmole": { "command": "npx", "args": ["-y", "dbmole-mcp"] }
}
}
```
**Docker**
The image is built from source:
```bash
git clone https://github.com/ed-smartass/dbmole-mcp.git && cd dbmole-mcp
docker build -f packages/dbmole-mcp/Dockerfile -t dbmole-mcp .
```
```json
{
"mcpServers": {
"dbmole": {
"command": "docker",
"args": [
"run", "-i", "--rm",
"-v", "dbmole-store:/home/node/.config/dbmole",
"-v", "/abs/path/to/project:/work",
"-v", "/home/me/.ssh/known_hosts:/home/node/.ssh/known_hosts:ro",
"dbmole-mcp"
]
}
}
}
```
The container runs as `node` with cwd `/work`: mount a project there to use its
`.dbmole.json`, and the named volume keeps the global store. Mount `known_hosts` for SSH
connections (or pin `ssh.hostKey`), and any private key you reference by `privateKeyPath`, at
the path the connection names; for `ssh.agent: true`, forward the agent socket
(`-v "$SSH_AUTH_SOCK:/ssh-agent" -e SSH_AUTH_SOCK=/ssh-agent`). To reach hosts that only your machine can reach, add
`--add-host=host.docker.internal:host-gateway` (Linux) and use `host.docker.internal`. The
image has no `git`, so the "not ignored by git" check always warns.
A 0.1 setup that still sets `DBMOLE_CONNECTIONS`, `DBMOLE_CONFIG` or `--config` starts fine:
the server prints one line on stderr saying they are ignored. See the
[changelog](https://github.com/ed-smartass/dbmole-mcp/blob/main/CHANGELOG.md#migrating-from-01).
## Quick start
Ask the agent, for example:
> Add a readonly postgres connection `shop` to this project: host 10.0.0.12, database shop,
> user reporter, through ssh as deploy@bastion.example.com with my ssh agent. Then show the
> five largest tables.
It calls `add_connection` with:
```json
{
"name": "shop",
"type": "postgres",
"host": "10.0.0.12",
"user": "reporter",
"password": "…",
"database": "shop",
"readonly": true,
"ssh": { "host": "bastion.example.com", "user": "deploy", "agent": true },
"scope": "project"
}
```
then `test_connection`, `list_tables` and `execute_sql`. Credentials you type in chat pass
through the model's context; for production secrets, write the entry into the file yourself.
## Connections
### Two layers
| Layer | File | Shape |
| --- | --- | --- |
| `project` | `.dbmole.json`, found from the server's working directory | `{ "connections": [ ... ] }` |
| `global` | `~/.config/dbmole/connections.json`, or the path in `DBMOLE_STORE` | `[ ... ]` |
- **Same name in both: the project entry wins.** `list_connections` reports each connection's
`source` (`project` or `global`) and, when it hides an entry of the same name in the other
layer, `shadows`.
- **Hot reload.** Both files are re-read on every tool call. Edit a file mid-session and the next
call uses the new settings; a changed connection gets a fresh pool, the old one is closed.
- **Project file discovery.** Starting from the server's working directory (Claude Code and
Codex start it in the project directory), dbmole walks up to the filesystem root and uses
the first `.dbmole.json` it finds. In a linked git worktree with no file of its own, it falls
back to the main checkout's `.dbmole.json`, so every worktree of a repo shares one file.
- Both files are plain JSON with mode `0600`, written atomically. Writes keep entries they
cannot parse verbatim, and refuse to overwrite a file that is not valid JSON.
### Managing connections with tools
- `add_connection` takes the connection fields plus `scope`: `"global"` (default) or
`"project"`. With `project` and no file yet, the file is created at the main checkout root
(or the git root, or the working directory outside git). If git does not ignore it, the
response warns you; add `.dbmole.json` to `.gitignore` so credentials are not committed.
- `add_connection` fails when the name already exists in the target layer. The same name in
the other layer is allowed; the response says which entry now shadows which.
- `update_connection` patches the connection where it lives (the winning layer). A `null`
value removes an optional field. An `ssh` object is merged into the stored one field by
field, so `{ "ssh": { "hostKey": "SHA256:..." } }` keeps the stored SSH secrets; `ssl` is
replaced as a whole.
- `remove_connection` deletes it from that layer and tells you if that uncovers a same-name
entry in the other layer.
- Credentials are never echoed back: `list_connections` shows host, port, database,
`readonly`, `source` and whether SSH is used.
### Broken and invalid entries
- An entry that fails validation does not silently disappear: its name resolves to an error
(`connection 'x' in <file> is invalid: ...`) instead of falling through to a same-name entry
in the global store, and `list_connections` lists it as invalid. A name defined twice in one
file is an error too. `remove_connection` can delete an invalid entry.
- A file that exists but is unreadable, not JSON, or the wrong shape is reported in
`list_connections` (`brokenLayers`). A broken project file blocks every connection; a broken
global store blocks only names the project file does not define. A missing file is just
empty.
### Connection fields
Unknown fields are rejected.
| Field | Type | Notes |
| --- | --- | --- |
| `name` | string | `[a-zA-Z0-9_-]+` |
| `type` | `postgres` \| `mysql` | |
| `host` | string | as seen from the SSH bastion when `ssh` is set |
| `port` | number | default `5432` / `3306` |
| `user` | string | |
| `password` | string | optional |
| `database` | string | default database for queries and schema tools; PostgreSQL falls back to `postgres` for `list_databases` and `test_connection` |
| `readonly` | boolean | default `false`, see [Readonly](#readonly) |
| `queryTimeoutMs` | integer | milliseconds, default `60000`, at most `2147483647`; see [Limits and timeouts](#limits-and-timeouts) |
| `ssl` | `true` or object | see [TLS](#tls) |
| `ssh` | object | see [SSH tunnels](#ssh-tunnels) |
Example `.dbmole.json`:
```json
{
"connections": [
{
"name": "local",
"type": "postgres",
"host": "localhost",
"user": "app",
"password": "app",
"database": "app"
},
{
"name": "shop-replica",
"type": "mysql",
"host": "10.0.0.12",
"user": "reporter",
"password": "s3cret",
"database": "shop",
"readonly": true,
"ssh": { "host": "bastion.example.com", "user": "deploy", "agent": true }
}
]
}
```
## SSH tunnels
| `ssh` field | Notes |
| --- | --- |
| `host`, `port` | bastion; port defaults to `22` |
| `user` | SSH user |
| `password` | password auth |
| `privateKey` / `privateKeyPath` | key contents, or a path (`~` is expanded) |
| `passphrase` | for an encrypted key |
| `agent` | `true` to use the agent at `SSH_AUTH_SOCK` |
| `hostKey` | pinned host key fingerprint, `SHA256:...` (OpenSSH format) |
```json
{ "host": "bastion.example.com", "user": "deploy", "privateKeyPath": "~/.ssh/id_ed25519" }
{ "host": "bastion.example.com", "user": "deploy", "password": "…" }
{ "host": "bastion.example.com", "port": 2222, "user": "deploy", "agent": true }
{ "host": "bastion.example.com", "user": "deploy", "agent": true, "hostKey": "SHA256:EXAMPLEexampleEXAMPLEexampleEXAMPLEexample1" }
```
**Host keys are verified.** With `hostKey` set, the bastion's key must match it (trailing `=`
padding is accepted) and `known_hosts` is not consulted. Otherwise the key must match an entry
for the host in `~/.ssh/known_hosts` (`host` on port 22, `[host]:port` otherwise):
- Plain and hashed host names match. Wildcard patterns never match, and a line with a negated
wildcard (`!*.example.com`) is ignored.
- A key listed under `@revoked` is rejected for every host, whatever the line's host pattern.
`@cert-authority` lines and unknown markers are skipped.
There is no trust-on-first-use: an unknown key fails the connection with an error that shows
the presented fingerprint. Check it against a trusted source, then either add the host to
`known_hosts` or pin it:
```bash
ssh-keyscan -p 22 bastion.example.com 2>/dev/null | ssh-keygen -lf -
# 256 SHA256:EXAMPLEexampleEXAMPLEexampleEXAMPLEexample1 bastion.example.com (ED25519)
```
and ask the agent to `update_connection` with `ssh.hostKey` set to that `SHA256:...` value.
Tunnels send keepalives every 15 s and are rebuilt after 3 missed replies. Not supported:
`ProxyJump` and `~/.ssh/config`, SSH certificates.
## TLS
| `ssl` value | Meaning |
| --- | --- |
| absent | no TLS |
| `true` | TLS, certificate chain and hostname verified |
| `{ "ca": "..." }` | verify against this CA: a PEM string or a file path (`~` expanded) |
| `{ "rejectUnauthorized": false }` | TLS without verification |
The hostname checked is always the connection's `host`, also when the connection goes through
an SSH tunnel. MySQL cannot verify the identity of an IP address, so a MySQL connection with an
IP `host` and verifying TLS is rejected at validation: use a hostname, or set
`ssl.rejectUnauthorized: false`.
`update_connection` replaces `ssl` as a whole (unlike `ssh`, it is not merged).
`list_connections` does not show TLS settings.
## Readonly
`readonly: true` protects against accidental writes. The database session enforces it, not a
SQL parser:
- PostgreSQL: each `execute_sql` call runs as `BEGIN READ ONLY` → statement → `ROLLBACK`.
- MySQL: each call runs on a session set to `SET SESSION TRANSACTION READ ONLY`.
- Every call gets a clean session: after it, the connection is reset (open transaction,
autocommit, session variables, current database, temporary tables), so nothing one call
sets, including an attempt to switch readonly off with `SET`, carries into the next call.
PostgreSQL runs `ROLLBACK` and `DISCARD ALL`; MySQL sends `COM_RESET_CONNECTION`, one extra
round trip per call. A connection whose reset fails (or, on MySQL, takes over 5 s) is closed,
never reused. This applies to writable connections too.
- One statement per call; multi-statement strings are refused by the protocol.
What it is not:
- **Not a security boundary.** The agent can switch it off with `update_connection`, by
design.
- **Known gaps include** (the list is not exhaustive):
- server-side file and program writes: PostgreSQL `COPY ... TO PROGRAM`,
`COPY ... TO '<file>'` and `lo_export`, MySQL `SELECT ... INTO OUTFILE` / `INTO DUMPFILE`;
- writes through `dblink`;
- DML on temporary tables;
- privileged administrative statements and functions, such as `pg_terminate_backend`,
`SET GLOBAL` and `KILL`.
For a hard guarantee, connect as a least-privilege database role with no write grants, no file,
program or administrative privileges, and no write-capable routines.
## Tools
| Tool | What it does |
| --- | --- |
| `list_connections` | connections with their `source`, shadowed names, invalid entries and broken files |
| `add_connection` | add a connection to the `project` file or the `global` store |
| `update_connection` | patch a connection where it lives; `null` removes a field |
| `remove_connection` | remove a connection; reports a same-name entry it uncovers |
| `test_connection` | connect end to end (including the tunnel) and report server version and latency |
| `execute_sql` | run one statement with positional params (`$1`… for PostgreSQL, `?` for MySQL); `rowLimit` default 100, max 1000; optional `database` |
| `list_databases` | databases on the server with their size; hides PostgreSQL templates and MySQL system schemas |
| `list_tables` | tables, views and materialized views (`type`: `table` or `view`) with approximate row counts |
| `describe_table` | columns, primary key, indexes and foreign keys of a table or view; accepts `schema.table` (PostgreSQL) and `db.table` (MySQL), with `"quoted"` or `` `quoted` `` parts that may contain dots |
Tool arguments are checked strictly: a wrong key is rejected with a hint, e.g.
`unknown key 'query' — did you mean 'sql'?`.
PostgreSQL `COPY ... FROM STDIN` and `COPY ... TO STDOUT` are refused: use `INSERT` and
`SELECT`. A `COPY ... TO STDOUT` still runs to the end on the server (its output is discarded,
`queryTimeoutMs` bounds it) before the call fails.
MySQL errors come with hints where they help: the real columns of the tables in the query on
an unknown column, similar table names on an unknown table, and a reminder to backtick-quote a
reserved word on a parse error.
The nine tool definitions cost about 1.8k tokens of context (`tools/list` is about 7,100
characters; measured with `npm run smoke`, at roughly 4 characters per token).
## Limits and timeouts
- Every result is at most 40 KB of JSON. Strings longer than 2 KB are cut and marked
`…[+N bytes]`; if rows still do not fit, whole rows are dropped from the end and `rowCount`
is the number of rows kept. The result says so in `truncated`
(`{ "reason": "budget", "dropped": N, "kept": M }`), and stays valid JSON.
- `execute_sql` stops reading at `rowLimit` rows
(`truncated: { "reason": "rowLimit", "limit": N }`); the
database streams rows (PostgreSQL cursor, MySQL stream), so a huge table never lands in
memory. The limits count rows: one enormous cell is still read in full before it is cut.
- `queryTimeoutMs` (default 60 s) bounds each statement: PostgreSQL cancels it on the server
(`statement_timeout`), which only helps while the server is reachable; if the network drops
silently, TCP keepalive detects the dead peer and fails the call; on MySQL the client stops waiting, sends `KILL QUERY` over a separate
short-lived connection (the server would otherwise keep running a statement that produces no
output), then discards the connection.
- Behind a load balancer or a DNS-rotated endpoint (an Aurora reader endpoint, HAProxy), that
separate connection can reach a different MySQL server: the `KILL QUERY` then misses the
statement, or, in theory, hits another session with the same thread id. Point MySQL
connections at a direct server endpoint if you rely on timeouts.
- A dropped connection resets the pool. `list_databases`, `list_tables`, `describe_table` and
`test_connection` retry once; `execute_sql` never replays a statement and tells you it may or
may not have run.
## How it compares
| | dbmole-mcp | [DBHub](https://github.com/bytebase/dbhub) | [Postgres MCP Pro](https://github.com/crystaldba/postgres-mcp) | [mcp-server-mysql](https://github.com/benborla/mcp-server-mysql) | [MCP Toolbox](https://github.com/googleapis/mcp-toolbox) |
| --- | --- | --- | --- | --- | --- |
| PostgreSQL | ✓ | ✓ | ✓ | ✗ | ✓ |
| MySQL | ✓ | ✓ | ✗ | ✓ | ✓ |
| Other databases | ✗ | ✓ | ✗ | ✗ | ✓ |
| SSH tunnel built in | ✓ | ✓ | — | ✓ | ✗ |
| Agent adds and edits connections through MCP tools | ✓ | ✗ ([not planned](https://github.com/bytebase/dbhub/issues/319)) | ✗ | ✗ | ✗ |
| Index tuning | ✗ | — | ✓ | — | — |
| Health checks | ✗ | ✓ | ✓ | — | ✓ (prebuilt PostgreSQL tools) |
✓ documented, ✗ not offered, — not mentioned in the project's docs. Checked October 2026;
corrections welcome.
## Security
Connection files hold plaintext credentials (mode `0600`, like `~/.pgpass`). Keep
`.dbmole.json` out of git. Database errors are passed to the client verbatim.
Whoever can change a connection, through `update_connection` or by editing a connection file,
can redirect its credentials. Changing `host` keeps the stored password, and changing
`ssh.host` keeps the stored SSH password or key, so the next call sends them to the new host.
Treat write access to the connection tools and files like access to the credentials.
A project's `.dbmole.json` is trusted as is: in a cloned or untrusted repository it can add
connections or shadow a global one of the same name and send your queries to another host.
Discovery walks up to `/`, so a file in a parent directory (such as `~`) applies to every
project below it. Check `list_connections` before working in an unfamiliar repository.
Each open SSH tunnel listens on `127.0.0.1` at a random port without authentication: while it
is open, any local process, including other users on a shared host, can connect through it
to the target host. The database still asks for its own credentials.
See [SECURITY.md](https://github.com/ed-smartass/dbmole-mcp/blob/main/SECURITY.md) for the
threat model and how to report a vulnerability.
## Development
```bash
npm ci
npm run lint # Biome
npm run typecheck # tsc across packages
npm run test:unit # unit tests, mocked IO
npm run test:int # integration tests against real databases (needs Docker)
npm run smoke # build, npm pack, install the tarballs in a temp dir, boot, tools/list
```
See [CONTRIBUTING.md](https://github.com/ed-smartass/dbmole-mcp/blob/main/CONTRIBUTING.md).
### Monorepo layout
```text
packages/
core/ @dbmole/core: registry, project files, SSH tunnels, pools, MCP connection tools
dbmole-mcp/ the PostgreSQL and MySQL server (this README)
```
`@dbmole/core` is published to npm because
[esmole-mcp](https://github.com/ed-smartass/esmole-mcp) builds on it; dbmole-mcp bundles it,
so installing dbmole-mcp pulls no `@dbmole/core`.
## License
[MIT](https://github.com/ed-smartass/dbmole-mcp/blob/main/LICENSE)
This server cannot be deployed
Maintenance
ActivityMaintained
ResponsivenessNo issues
