Power BI MCP Server

Disclaimer: This is an independent, community-developed tool and is not affiliated with, endorsed by, or connected to Microsoft Corporation or Anthropic.

Overview

Power BI MCP Server bridges the gap between AI assistants and Microsoft Power BI, enabling seamless interaction with semantic models through the Model Context Protocol. Whether you're working with local .pbix files or cloud-hosted datasets, this server provides a unified interface for querying data, managing models, and performing bulk operations—all while maintaining enterprise-grade security.

Key Capabilities

Capability	Description
Dual Connectivity	Connect to both Power BI Desktop (local) and Power BI Service (cloud)
Natural Language Queries	Execute DAX queries through conversational AI
Bulk Operations	Rename tables, columns, and measures across your model
Security First	PII detection, audit logging, and configurable access policies
RLS Testing	Test Row-Level Security roles during development
Safe Refactoring	PBIP-based editing preserves report visual integrity

Related MCP server: Metabase MCP Server

The V1 to V2 Journey: Challenges & Solutions

The Challenge: Bulk Renames Breaking Reports

In V1, we successfully connected to Power BI Service via XMLA endpoints. V2 introduced Power BI Desktop connectivity and write operations using Microsoft's Tabular Object Model (TOM). However, we encountered a critical limitation:

Problem: Renaming a table via TOM breaks all report visuals referencing that table.

Root Cause Analysis:

Power BI stores data in two separate layers:

When you rename a table using TOM, it updates:

The table name in the model
DAX expressions in measures (with our auto-update logic)
Relationship references

But it cannot update:

Visual field bindings in report.json
Slicer configurations
Bookmark references

This causes visuals to show errors like "Can't find column 'OldTableName'[Column]".

The Solution: PBIP File-Based Editing

We researched Microsoft's own approach and discovered that even their tools face this limitation. The solution lies in the Power BI Project (PBIP) format—a text-based representation of both the model and report.

Two Report Formats Supported:

Format	Structure	Default
PBIR-Legacy	Single `report.json`	Until Jan 2026
PBIR-Enhanced	Individual `visual.json` files	From Jan 2026

MyReport.pbip ├── MyReport.SemanticModel/ │ ├── definition.tmdl <- Model definitions (text) │ └── definition/ │ ├── tables/*.tmdl <- Table definitions │ ├── cultures/*.tmdl <- Linguistic schema (Q&A) │ └── relationships.tmdl └── MyReport.Report/ ├── report.json <- PBIR-Legacy: All visuals here ├── definition.pbir └── definition/ <- PBIR-Enhanced structure ├── report.json <- Report-level settings only └── pages/ └── [page_id]/ └── visuals/ └── [visual_id]/ └── visual.json <- Individual visual definition

Reference: Data Goblins - Programmatically Modify Reports

Our Implementation:

We built a dedicated PBIP Connector that:

Parses PBIP Structure - Locates all TMDL files and report.json
Updates Model Layer - Regex-based find-replace in TMDL files for:
- Table definitions (table OldName → table NewName)
- DAX references ('OldTable'[Column] → 'NewTable'[Column])
Updates Report Layer - JSON manipulation in report.json for:
- Entity bindings ("Entity": "OldTable" → "Entity": "NewTable")
- Query references ("OldTable.Column" → "NewTable.Column")
- Native reference names

Result: Tables, columns, and measures can be renamed without breaking a single visual.

Lessons Learned

Challenge	Solution
TOM can't modify report layer	PBIP file-based editing
DAX references not auto-updating	Regex-based expression rewriting
No visibility into rename impact	`scan_table_dependencies` tool
Complex PBIP structure	Dedicated connector with path discovery

Architecture

┌──────────────────────────────────────────────────────────────┐ │ AI Assistant │ │ (Claude Desktop / Claude Code) │ └─────────────────────────────┬────────────────────────────────┘ │ MCP Protocol ▼ ┌──────────────────────────────────────────────────────────────┐ │ Power BI MCP Server │ │ (34 Tools) │ ├──────────────────────────────────────────────────────────────┤ │ ┌─────────────┐ ┌─────────────┐ ┌─────────────────────┐ │ │ │ Security │ │ Audit │ │ Access Policies │ │ │ │ (PII Mask) │ │ Logger │ │ (Block/Mask) │ │ │ └─────────────┘ └─────────────┘ └─────────────────────┘ │ ├──────────────────────────────────────────────────────────────┤ │ ┌─────────────┐ ┌─────────────┐ ┌─────────────────────┐ │ │ │ Desktop │ │ XMLA │ │ PBIP │ │ │ │ Connector │ │ Connector │ │ Connector │ │ │ │ (ADOMD) │ │ (Cloud) │ │ (File Editing) │ │ │ └──────┬──────┘ └──────┬──────┘ └──────────┬──────────┘ │ │ │ │ │ │ │ ┌──────┴──────┐ ┌──────┴──────┐ ┌──────────┴──────────┐ │ │ │ TOM │ │ REST API │ │ TMDL + JSON │ │ │ │ Connector │ │ Connector │ │ Parser │ │ │ └─────────────┘ └─────────────┘ └─────────────────────┘ │ └──────────────────────────────────────────────────────────────┘ │ │ │ ▼ ▼ ▼ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │ Power BI │ │ Power BI │ │ PBIP │ │ Desktop │ │ Service │ │ Files │ │ (localhost) │ │ (Cloud) │ │ (.pbip) │ └─────────────┘ └─────────────┘ └─────────────┘

Available Tools

Desktop Operations (7 tools)

Tool	Description
`desktop_discover_instances`	Auto-discover running Power BI Desktop instances
`desktop_connect`	Connect to a specific instance with optional RLS role
`desktop_list_tables`	List all tables in the connected model
`desktop_list_columns`	List columns for a specific table
`desktop_list_measures`	List all measures with their expressions
`desktop_execute_dax`	Execute DAX queries with security processing
`desktop_get_model_info`	Get comprehensive model metadata

Cloud Operations (6 tools)

Tool	Description
`list_workspaces`	List accessible Power BI Service workspaces
`list_datasets`	List datasets in a workspace
`list_tables`	List tables via XMLA endpoint
`list_columns`	List columns for a table
`execute_dax`	Execute DAX queries against cloud datasets
`get_model_info`	Get model info using INFO.VIEW functions

Security & Compliance (2 tools)

Tool	Description
`security_status`	View current security configuration
`security_audit_log`	Query recent audit log entries

Row-Level Security (3 tools)

Tool	Description
`desktop_list_rls_roles`	List RLS roles defined in the model
`desktop_set_rls_role`	Activate an RLS role for testing
`desktop_rls_status`	Get current RLS status

Model Modification via TOM (7 tools)

⚠️ WARNING: TOM-based rename tools are DEPRECATED for renaming operations!
The batch_rename_* TOM tools only update the in-memory model and DO NOT update report visuals. This causes broken visuals after rename. Use PBIP tools instead for all rename operations.

Tool	Description
`scan_table_dependencies`	Analyze impact before renaming
`batch_rename_tables`	⚠️ DEPRECATED - Use `pbip_rename_tables` instead
`batch_rename_columns`	⚠️ DEPRECATED - Use `pbip_rename_columns` instead
`batch_rename_measures`	⚠️ DEPRECATED - Use `pbip_rename_measures` instead
`batch_update_measures`	Bulk update measure expressions
`create_measure`	Create a new DAX measure
`delete_measure`	Delete an existing measure

PBIP Safe Editing (5 tools) ✅ RECOMMENDED

This is the correct way to rename tables, columns, and measures!
PBIP tools update everything: TMDL files, DAX expressions (with proper quoting), report visuals, and Q&A schema. Close Power BI Desktop before using, then reopen after.

Tool	Description
`pbip_load_project`	Load a PBIP project for editing
`pbip_get_project_info`	Get project structure information (detects PBIR format)
`pbip_rename_tables`	✅ Comprehensive rename: updates TMDL + DAX quoting + visual.json + cultures (all automatic)
`pbip_rename_columns`	✅ Rename columns (model + report layer, both PBIR formats)
`pbip_rename_measures`	✅ Rename measures (model + report layer, both PBIR formats)

PBIP Diagnostics (4 tools)

Tool	Description
`pbip_fix_broken_visuals`	Fix visual references after TOM/API rename (when rename was done outside PBIP tools)
`pbip_fix_dax_quoting`	Fix any remaining unquoted table names in DAX expressions
`pbip_scan_broken_refs`	Scan project for broken references - compare model vs visuals
`pbip_validate`	Validate TMDL syntax, find quoting issues, invalid references

Note: DAX quoting and visual updates are now automatically handled by pbip_rename_tables. The repair tools are only needed when renames were done outside of PBIP (e.g., via TOM API or Power BI Desktop).

Security Features

PII Detection & Auto-Masking

Sensitive data is automatically detected and masked before being returned to the AI:

Pattern	Example	Masked Output
SSN	`123-45-6789`	`*--6789`
Credit Card	`4111-1111-1111-1234`	`**--**-1234`
Email	`john@company.com`	`j*@c**.com`
Phone	`(555) 123-4567`	`(*) *-4567`

Query Audit Logging

Every query is logged with:

Timestamp and unique query fingerprint
Row count and execution duration
PII detection results
Policy violation flags

Logs support compliance requirements (GDPR, HIPAA, SOC2).

Configurable Access Policies

Define granular policies in config/policies.yaml:

tables: - name: Customers columns: - name: SSN action: block # Never return - name: Email action: mask # Apply PII masking - name: Revenue action: allow # Return as-is

Installation

Prerequisites

For Desktop Connectivity:

Windows 10/11
Power BI Desktop installed
Python 3.10+
ADOMD.NET (included with Power BI Desktop or SSMS)

For Cloud Connectivity (Optional):

Azure AD App Registration with Dataset.Read.All and Workspace.Read.All
Premium Per User (PPU) or Premium Capacity workspace
XMLA endpoint enabled

Quick Start

# Clone the repository git clone https://github.com/sulaiman013/powerbi-mcp.git cd powerbi-mcp-v2 # Install dependencies pip install -r requirements.txt # (Optional) Configure cloud credentials cp .env.example .env # Edit .env with your Azure AD credentials

Configure Claude Desktop

Add to %APPDATA%\Claude\claude_desktop_config.json:

{ "mcpServers": { "powerbi": { "command": "python", "args": ["C:/path/to/powerbi-mcp-v2/src/server.py"], "env": { "PYTHONPATH": "C:/path/to/powerbi-mcp-v2/src" } } } }

Restart Claude Desktop to activate.

Usage Examples

⚠️ IMPORTANT: How to Rename Tables/Columns/Measures

DO NOT use TOM-based tools (batch_rename_tables, batch_rename_columns, batch_rename_measures) for renaming. They break report visuals!

ALWAYS use PBIP tools:

Close Power BI Desktop (if open)
pbip_load_project - Load the .pbip file
pbip_rename_tables / pbip_rename_columns / pbip_rename_measures - Do the rename
Reopen Power BI Desktop to see changes

Basic Desktop Workflow

User: "Discover Power BI Desktop instances" User: "Connect to Power BI Desktop" User: "What tables are in my model?" User: "Run DAX: EVALUATE TOPN(10, Sales)"

Safe Bulk Rename with PBIP (✅ Correct Way)

User: "Load PBIP project from C:/Projects/SalesReport" User: "Rename tables: Salesforce_Data to Leads Sales Data"

What happens automatically:

Table declaration updated: table Salesforce_Data → table 'Leads Sales Data'
DAX references quoted: Salesforce_Data[Amount] → 'Leads Sales Data'[Amount]
Function calls fixed: COUNTROWS(Salesforce_Data) → COUNTROWS('Leads Sales Data')
Visual files updated: All "Entity": "Salesforce_Data" → "Entity": "Leads Sales Data"
Cultures/Q&A updated: All "ConceptualEntity" references fixed

Diagnose Issues (When Needed)

User: "Load PBIP project from C:/Projects/SalesReport" User: "Scan for broken references" # Shows: Tables in model vs tables referenced in visuals User: "Validate project" # Shows: Any TMDL syntax errors or quoting issues

Use repair tools only if a rename was done outside the MCP server (e.g., via TOM API or Power BI Desktop UI).

RLS Testing

User: "List RLS roles in my model" User: "Set RLS role to 'Sales_East'" User: "Run DAX: EVALUATE Sales" # Results filtered by role User: "Clear RLS role"

Project Structure

powerbi-mcp-v2/ ├── src/ │ ├── server.py # MCP server (30 tools) │ ├── powerbi_desktop_connector.py # Desktop + RLS │ ├── powerbi_xmla_connector.py # Cloud XMLA │ ├── powerbi_rest_connector.py # REST API │ ├── powerbi_tom_connector.py # TOM write operations │ ├── powerbi_pbip_connector.py # PBIP file editing │ └── security/ │ ├── pii_detector.py # PII detection │ ├── audit_logger.py # Audit logging │ ├── access_policy.py # Policy engine │ └── security_layer.py # Unified security ├── config/ │ └── policies.yaml # Access policies ├── logs/ │ └── audit.log # Query audit log ├── .env.example ├── requirements.txt └── README.md

Limitations

Limitation	Workaround
Windows only	Required for ADOMD.NET and Power BI Desktop
TOM renames break visuals	Use PBIP tools for safe bulk renames
Cloud requires Premium	XMLA endpoints need PPU/Premium workspace

Roadmap

Completed (V2)

Power BI Desktop connectivity
Cloud XMLA integration
Security layer (PII, audit, policies)
RLS testing support
TOM write operations
PBIP safe editing

Planned (V3)

Open Source LLM Support - Integration with Ollama, LM Studio, and other local LLMs
Air-Gapped Deployment - Full offline capability for secure enterprise environments
Docker Containerization - One-command deployment with docker-compose
Self-Hosted Architecture - Run entirely on-premise without external dependencies
Relationship management (create/delete)
VertiPaq Analyzer integration
Auto-generated model documentation
Cross-platform support exploration

Author

Sulaiman Ahmed Data Analytics Engineer & Microsoft Certified Professional

Passionate about bridging the gap between AI and enterprise data platforms. This project combines expertise in Power BI semantic modeling, Python development, and the emerging Model Context Protocol ecosystem.

GitHub Portfolio

Contributing

Contributions are welcome! Please read our contributing guidelines before submitting PRs.

Fork the repository
Create a feature branch (git checkout -b feature/amazing-feature)
Commit your changes (git commit -m 'Add amazing feature')
Push to the branch (git push origin feature/amazing-feature)
Open a Pull Request

License

This project is licensed under the MIT License - see the LICENSE file for details.
