Auckland Transport MCP Server

A Model Context Protocol (MCP) server for connecting to the Auckland Transport API. This server provides tools to search for public transport stops and retrieve transit information using the General Transit Feed Specification (GTFS) format.

Features

• Stop Search: Search for Auckland Transport stops by name (case-insensitive substring match)

• Stop Trip Information: Retrieve scheduled trips and timetables for specific stops

• GTFS Integration: Uses General Transit Feed Specification for standardized transit data exchange

• FastMCP Framework: Built on FastMCP for easy MCP server development

• Type Safety: Full type hints and Pydantic models for data validation

Prerequisites

• Python >= 3.11

• uv package manager (recommended) or pip

• Auckland Transport API credentials

Installation

1. Clone the repository:

2. Install dependencies using uv:

Or using pip:

Configuration

Create a .env file in the root directory with your Auckland Transport API credentials:

Note: Make sure to add .env to your .gitignore file (already included) to keep your API keys secure.

Usage

Running the MCP Server

Start the MCP server:

Testing

Run the test script to verify the connection:

Using the Tools

The server provides the following MCP tools:

search_stop(name: str) -> StopResponse

Searches for Auckland Transport stops by name (case-insensitive substring match).

Parameters:

• name (str): The stop name to search for

Returns:

• StopResponse: A Pydantic model containing a list of matching stops with attributes including:

  • stop_id: Unique identifier for the stop

  • stop_code: Public-facing stop code

  • stop_name: Name of the stop

  • stop_lat: Latitude coordinate

  • stop_lon: Longitude coordinate

  • location_type: Type of location (0=stop, 1=station, etc.)

  • wheelchair_boarding: Wheelchair accessibility information (0=unknown, 1=accessible, 2=not accessible)

Example:

get_stop_trips_by_stop_id(stop_id: str) -> StopTripResponse

Retrieves scheduled trips for a specific stop on the current date and hour.

Parameters:

• stop_id (str): The unique identifier of the stop

Returns:

• StopTripResponse: A Pydantic model containing a list of stop trips with attributes including:

  • arrival_time: Scheduled arrival time (HH:MM:SS format)

  • departure_time: Scheduled departure time (HH:MM:SS format)

  • route_id: Identifier for the route

  • trip_headsign: Text displayed on the vehicle for this trip

  • stop_headsign: Text displayed on signage at the stop

  • stop_sequence: Order of this stop in the trip sequence

  • direction_id: Direction of travel (0 or 1)

  • service_date: Date of service (YYYY-MM-DD format)

  • shape_id: Identifier for the shape/geometry of the route

  • pickup_type: Pickup type (0=regular, 1=none, 2=phone, 3=driver)

  • drop_off_type: Drop-off type (0=regular, 1=none, 2=phone, 3=driver)

Example:

Project Structure

Dependencies

• fastmcp>=2.13.2: FastMCP framework for building MCP servers

• dotenv>=0.9.9: Environment variable management

• pydantic: Data validation and modeling for GTFS structures

• requests: HTTP library for API calls

Note: The project uses uv for dependency management. All dependencies are specified in pyproject.toml.

Development

Adding New Tools

To add new MCP tools, edit src/app.py and add new tool functions decorated with @mcp.tool:

API Reference

The Auckland Transport API uses GTFS (General Transit Feed Specification) for data exchange. For more information about the API, visit the Auckland Transport API documentation.

Data Models

The project uses Pydantic models defined in gtfs_types.py to validate and structure API responses:

• StopAttributes: Contains stop location and accessibility information

• Stop: Represents a single stop resource with type, ID, and attributes

• StopResponse: Container for multiple stop search results

• StopTripAttributes: Contains trip timing, route, and service information

• StopTrip: Represents a single stop trip resource

• StopTripResponse: Container for multiple stop trip results

All models follow the GTFS standard and are fully typed for better IDE support and error checking.

Troubleshooting

Common Issues

1. API Key Not Found: Ensure your .env file exists in the root directory and contains both AT_BASE_URL and AT_API_KEY.

2. Empty Results: The API returns data for the current date and hour. If searching for trips, ensure there are scheduled services at the current time.

3. Connection Errors: Verify your internet connection and that the Auckland Transport API is accessible from your network.

References

• GTFS Static Overview - Google Developers - Official Google documentation for GTFS (General Transit Feed Specification)

• GTFS Documentation - gtfs.org - Official GTFS specification documentation maintained by MobilityData
