mcp-primer

MCP App that renders Primer React components inline in AI conversations. Built on the MCP Apps extension.

What it does

Exposes two MCP tools:

The LLM sends a component tree as JSON, and the MCP App renders it using real @primer/react components with full GitHub theming (light + dark mode).

Example

Ask Copilot: "Show me a PR status using Primer components"

The LLM calls render-primer with:

{
  "tree": {
    "type": "Stack",
    "props": { "direction": "horizontal", "align": "center", "gap": "normal" },
    "children": [
      { "type": "StateLabel", "props": { "status": "pullOpened" }, "children": "Open" },
      { "type": "Heading", "props": { "as": "h3" }, "children": "Add dark mode support" }
    ]
  }
}

And it renders as real Primer components in the chat.

Setup

VS Code (Insiders)

Add to your MCP settings (.vscode/mcp.json):

{
  "servers": {
    "primer": {
      "command": "node",
      "args": ["${workspaceFolder}/dist/main.js", "--stdio"]
    }
  }
}

Or point to the repo wherever you cloned it:

{
  "servers": {
    "primer": {
      "command": "bash",
      "args": ["-c", "cd ~/source/mcp-primer && npm run build >&2 && node dist/main.js --stdio"]
    }
  }
}

HTTP Transport

npm start
# Server listening on http://localhost:3001/mcp

Development

npm install
npm run dev     # Watch mode (Vite + server)

Available Components

Layout: Stack, PageLayout, PageHeader

Typography: Heading, Text

Actions: Button, IconButton, ButtonGroup, LinkButton

Navigation: Breadcrumbs, Link, Pagination, UnderlineNav

Data Display: Avatar, AvatarStack, BranchName, CounterLabel, Label, StateLabel, Token, RelativeTime, Timeline

Feedback: Banner, Spinner, ProgressBar

Forms: TextInput, Textarea, Select, Checkbox, Radio, FormControl, ToggleSwitch, SegmentedControl

Overlays: ActionList, ActionMenu, Dialog

Misc: Truncate, Tooltip, Popover, TreeView, NavList

All compound components (e.g. ActionList.Item, FormControl.Label, Timeline.Badge) are also supported using dot notation.

Component Tree Format

Each node in the tree has:

{
  type: string;       // Primer component name
  props?: object;     // Component props
  children?: string | node | (string | node)[];  // Text or nested components
}

Build

npm run build    # Type-check + Vite bundle + compile server

Produces:

• dist/mcp-app.html — single-file React app with all Primer components bundled

• dist/server.js — MCP server

• dist/index.js — entry point (stdio + HTTP)
